11_MCX-50 Series
Manufacturer: Huber+Suhner, Inc.
Beta
⌘K
11_MCX-50-2-16/133_NH
| Part | Center Contact Plating | Body Finish | Dielectric Material | Voltage Rating | Body Material | Operating Temperature [Max] | Operating Temperature [Min] | Mating Cycles | Number of Ports | Fastening Type | Center Contact Material | Frequency - Max [Max] | Contact Termination | Cable Group | Shield Termination | Connector Style | Mounting Type | Housing Color | Connector Type | Impedance | Cable Group |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Huber+Suhner, Inc. | Gold | White Bronze | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 170 V | Beryllium Copper | 155 C | -55 C | 500 | 1 | Snap-On | Brass | 6000 MHz | Crimp | 188 316 RG-174 | Crimp | MCX | Free Hanging (In-Line) | Silver | Plug Male Pin | 50 Ohms | |
 Huber+Suhner, Inc. | Gold | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 170 V | Brass | 155 C | -55 C | 500 | 1 | Snap-On | Brass | 6000 MHz | Crimp | 188 316 RG-174 | Crimp | MCX | Free Hanging (In-Line) | Gold | Plug Male Pin | 50 Ohms | |
 Huber+Suhner, Inc. | Gold | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 170 V | Beryllium Copper | 155 C | -65 ░C | 500 | 1 | Snap-On | Brass | 6000 MHz | Solder | RG-405 (.086 Semi Rigid) | Solder | MCX | Free Hanging (In-Line) | Gold | Plug Male Pin | 50 Ohms | |
Huber+Suhner, Inc. | Gold | White Bronze | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 170 V | Beryllium Copper | 155 C | -55 C | 500 | 1 | Snap-On | Brass | 6000 MHz | Crimp | RG-178 | Crimp | MCX | Free Hanging (In-Line) | Silver | Plug Male Pin | 50 Ohms | 196 |
 Huber+Suhner, Inc. | Gold | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 170 V | Brass | 155 C | -55 C | 500 | 1 | Snap-On | Brass | 6000 MHz | Crimp | RG-178 | Crimp | MCX | Free Hanging (In-Line) | Gold | Plug Male Pin | 50 Ohms | 196 |
 Huber+Suhner, Inc. | Gold | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 170 V | Brass | 155 C | -55 C | 500 | 1 | Snap-On | Brass | 6000 MHz | Crimp | RG-316 | Crimp | MCX | Free Hanging (In-Line) | Gold | Plug Male Pin | 50 Ohms | |
 Huber+Suhner, Inc. | Gold | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 170 V | Brass | 155 C | -65 ░C | 500 | 1 | Snap-On | Brass | 6000 MHz | Solder | RG-405 (.086 Semi Rigid) | Solder | MCX | Free Hanging (In-Line) | Gold | Plug Male Pin | 50 Ohms | |
 Huber+Suhner, Inc. | Gold | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 330 VDC | Brass Bronze | 155 C | -55 C | 1 | Snap-On | Beryllium Copper | 6000 MHz | Crimp | RD-316 | Crimp | MBX | Free Hanging (In-Line) | Gold | Plug Male Pin | 50 Ohms | ||
 Huber+Suhner, Inc. | Gold | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 170 V | Beryllium Copper | 155 C | -55 C | 500 | 1 | Snap-On | Brass | 6000 MHz | Solder | Solder | MCX | Free Hanging (In-Line) | Gold | Plug Male Pin | 50 Ohms | 0.047 in | |
 Huber+Suhner, Inc. | Gold | White Bronze | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 170 V | Beryllium Copper | 155 C | -55 C | 500 | 1 | Snap-On | Brass | 6000 MHz | Crimp | RD-316 | Crimp | MCX | Free Hanging (In-Line) | Silver | Plug Male Pin | 50 Ohms |
