VLDK1535 Series

Catalog

LED AMBER CLEAR 2SMD

Part	Configuration	Voltage - Forward (Vf) (Typ)	Lens Size [diameter]	Wavelength - Peak	Lens Color	Millicandela Rating	Lens Transparency	Lens Style	Color	Mounting Type	Package / Case	Viewing Angle	Size / Dimension [y]	Size / Dimension [x]	Height (Max) [z]	Wavelength - Dominant	Current - Test	Supplier Device Package
Vishay Semiconductor Opto Division VLDK1535G-08	Independent	2.25 V	1.8 mm Dia	622 nm	Colorless	8000 mcd	Clear	Round with Domed Top	Amber	Surface Mount	2-SMD Gull Wing	44 °	2.3 mm	2.3 mm	2.75 mm	616 nm	50 mA	2-SMD
Vishay Semiconductor Opto Division VLDK1535R-08	Independent	2.25 V	1.8 mm Dia	622 nm	Colorless	8000 mcd	Clear	Round with Domed Top	Amber	Surface Mount Bottom Entry	2-SMD Z-Bend	44 °	2.3 mm	2.3 mm	2.75 mm	616 nm	50 mA	2-SMD
