RFNA Series
Manufacturer: BULGIN LIMITED
Beta
⌘K
RF / COAXIAL CONNECTOR, N COAXIAL, STRAIGHT FLANGED JACK, SOLDER, 50 OHM, BERYLLIUM COPPER
| Part | Dielectric Material | Body Material | Voltage Rating | Mating Cycles | Operating Temperature [Max] | Operating Temperature [Min] | Center Contact Material | Features | Number of Ports | Fastening Type | Contact Termination | Housing Color | Mounting Type | Connector Type | Shield Termination | Connector Style | Frequency - Max [Max] | Mounting Feature | Impedance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BULGIN LIMITED | Polyetherimide (PEI) | Stainless Steel | 500 V | 500 | 155 C | -55 C | Beryllium Copper | Extended Insulation | 1 | Threaded | Solder | Silver | Panel Mount Through Hole | Female Socket Jack | Solder | N Type | 18 GHz | Flange | 50 Ohms |
BULGIN LIMITED | Polyetherimide (PEI) | Stainless Steel | 500 V | 500 | 155 C | -55 C | Beryllium Copper | Extended Insulation | 1 | Threaded | Solder | Silver | Panel Mount Through Hole | Female Socket Jack | Solder | N Type | 18 GHz | Flange | 50 Ohms |
 BULGIN LIMITED | Polyetherimide (PEI) | Stainless Steel | 500 V | 500 | 155 C | -55 C | Beryllium Copper | 1 | Threaded | Compression | Silver | Panel Mount | Plug Male Pin | Screw | N Type | 18 GHz | Flange | 50 Ohms | |
 BULGIN LIMITED | Polyetherimide (PEI) | Stainless Steel | 500 V | 500 | 155 C | -55 C | Beryllium Copper | 1 | Threaded | Compression | Silver | Panel Mount | Plug Male Pin | Screw | N Type | 18 GHz | Flange | 50 Ohms | |
 BULGIN LIMITED | Polyetherimide (PEI) | Stainless Steel | 500 V | 500 | 155 C | -55 C | Beryllium Copper | 1 | Threaded | Compression | Silver | Panel Mount | Female Socket Jack | Screw | N Type | 18 GHz | Flange | 50 Ohms | |
 BULGIN LIMITED | Polyetherimide (PEI) | Stainless Steel | 500 V | 500 | 155 C | -55 C | Beryllium Copper | 1 | Threaded | Solder | Silver | Panel Mount Through Hole | Plug Male Pin | Solder | N Type | 18 GHz | Flange | 50 Ohms | |
BULGIN LIMITED | Polyetherimide (PEI) | Stainless Steel | 500 V | 500 | 155 C | -55 C | Beryllium Copper | 1 | Threaded | Solder | Silver | Panel Mount Through Hole | Female Socket Jack | Solder | N Type | 18 GHz | Flange | 50 Ohms | |
 BULGIN LIMITED | Polyetherimide (PEI) | Stainless Steel | 500 V | 500 | 155 C | -55 C | Beryllium Copper | 1 | Threaded | Compression | Silver | Panel Mount | Female Socket Jack | Screw | N Type | 18 GHz | Flange | 50 Ohms | |
 BULGIN LIMITED | Polyetherimide (PEI) | Stainless Steel | 500 V | 500 | 155 C | -55 C | Beryllium Copper | 1 | Threaded | Compression | Silver | Panel Mount | Female Socket Jack | Screw | N Type | 18 GHz | Flange | 50 Ohms | |
BULGIN LIMITED | Polyetherimide (PEI) | Stainless Steel | 500 V | 500 | 155 C | -55 C | Beryllium Copper | 1 | Threaded | Compression | Silver | Panel Mount | Female Socket Jack | Screw | N Type | 18 GHz | Flange | 50 Ohms |
