325-006 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 6POS 0.100
| Part | Termination Rows | Material - Insulation | Contact Type | Number of Positions/Bay/Row | Contact Finish | Number of Rows | Contact Material | Termination | Card Type | Card Thickness | Card Thickness | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Min] | Operating Temperature [Max] | Color | Mounting Type | Pitch | Pitch | Gender | Number of Positions | Read Out | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Cantilever | 6 | Gold | 1 | Copper Alloy | Solder Eyelet(s) | Non Specified - Single Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | -65 ░C | 125 °C | Green | Through Hole | 0.1 " | 2.54 mm | Female | 6 | Single | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Cantilever | 6 | Gold | 1 | Copper Alloy | Wire Wrap | Non Specified - Single Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | -65 ░C | 125 °C | Green | Through Hole | 0.1 " | 2.54 mm | Female | 6 | Single | 4-40 Flush Mount Threaded Insert Top Opening | ||
EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Cantilever | 6 | Gold | 1 | Copper Alloy | Wire Wrap | Non Specified - Single Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | -65 ░C | 125 °C | Green | Through Hole | 0.1 " | 2.54 mm | Female | 6 | Single | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Cantilever | 6 | Gold | 1 | Copper Alloy | Wire Wrap | Non Specified - Single Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | -65 ░C | 125 °C | Green | Through Hole | 0.1 " | 2.54 mm | Female | 6 | Single | Flush Mount M3 Threaded Insert Top Opening | ||
EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Cantilever | 6 | Gold | 1 | Copper Alloy | Solder Eyelet(s) | Non Specified - Single Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | -65 ░C | 125 °C | Green | Through Hole | 0.1 " | 2.54 mm | Female | 6 | Single | Flush Mount Top Opening Unthreaded | 0.16 " | 4.06 mm |
EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Cantilever | 6 | Gold | 1 | Copper Alloy | Solder | Non Specified - Single Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | -65 ░C | 125 °C | Green | Through Hole | 0.1 " | 2.54 mm | Female | 6 | Single | Flush Mount Top Opening Unthreaded | 0.16 " | 4.06 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Cantilever | 6 | Gold | 1 | Copper Alloy | Solder | Non Specified - Single Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | -65 ░C | 125 °C | Green | Through Hole | 0.1 " | 2.54 mm | Female | 6 | Single | Flush Mount M3 Threaded Insert Top Opening | ||
EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Cantilever | 6 | Gold | 1 | Copper Alloy | Solder Eyelet(s) | Non Specified - Single Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | -65 ░C | 125 °C | Green | Through Hole | 0.1 " | 2.54 mm | Female | 6 | Single | 4-40 Flush Mount Threaded Insert Top Opening |
