0461-3 Series

Manufacturer: Mill-Max Manufacturing Corp.

Catalog

CONN PIN RCPT .015-.020 SOLDER

Part	Operating Temperature [Min]	Operating Temperature [Max]	Accepts Pin Diameter [Max]	Accepts Pin Diameter [Min]	Accepts Pin Diameter [Min]	Accepts Pin Diameter [Max]	Contact Finish Thickness	Contact Finish Thickness	Tail Type	Mounting Hole Diameter [diameter]	Mounting Hole Diameter [diameter]	Contact Finish	Termination	Pin Hole Diameter [diameter]	Pin Hole Diameter [diameter]	Flange Diameter [diameter]	Flange Diameter [diameter]	Socket Depth [z]	Socket Depth [z]	Length - Overall [x]	Length - Overall [x]	Tail Diameter [diameter]	Tail Diameter [diameter]	Contact Material	Accepts Pin Diameter [Max]
Mill-Max Manufacturing Corp. 0461-3-15-01-11-27-04-0	-55 C	125 °C	0.02 in	0.38 mm	0.015 "	0.51 mm	30 Áin	0.76 Ám	Standard Tail	0.02 in	0.51 mm	Gold	Solder	0.031 in	0.79 mm	0.041 in	1.04 mm	3.81 mm	0.15 in	0.3 "	7.62 mm	0.46 mm	0.018 in	Beryllium Copper
Mill-Max Manufacturing Corp. 0461-3-15-80-21-84-04-0	-55 C	125 °C	0.022 in	0.38 mm	0.015 "		100 µin	2.54 µm	Standard Tail	0.02 in	0.51 mm	Tin	Solder	0.031 in	0.79 mm	0.041 in	1.04 mm	3.81 mm	0.15 in	0.3 "	7.62 mm	0.46 mm	0.018 in	Beryllium Copper	0.56 mm
Mill-Max Manufacturing Corp. 0461-3-15-80-21-14-04-0	-55 C	125 °C	0.022 in	0.38 mm	0.015 "		10 Áin	0.25 Ám	Standard Tail	0.02 in	0.51 mm	Gold	Solder	0.031 in	0.79 mm	0.041 in	1.04 mm	3.81 mm	0.15 in	0.3 "	7.62 mm	0.46 mm	0.018 in	Beryllium Copper	0.56 mm
Mill-Max Manufacturing Corp. 0461-3-15-01-21-14-04-0	-55 C	125 °C	0.022 in	0.38 mm	0.015 "		10 Áin	0.25 Ám	Standard Tail	0.02 in	0.51 mm	Gold	Solder	0.031 in	0.79 mm	0.041 in	1.04 mm	3.81 mm	0.15 in	0.3 "	7.62 mm	0.46 mm	0.018 in	Beryllium Copper	0.56 mm
Mill-Max Manufacturing Corp. 0461-3-15-15-11-14-04-0	-55 C	125 °C	0.022 in	0.38 mm	0.015 "		10 Áin	0.25 Ám	Standard Tail	0.02 in	0.51 mm	Gold	Solder	0.031 in	0.79 mm	0.041 in	1.04 mm	3.81 mm	0.15 in	0.3 "	7.62 mm	0.46 mm	0.018 in	Beryllium Copper	0.56 mm
Mill-Max Manufacturing Corp. 0461-3-15-80-21-27-04-0	-55 C	125 °C	0.022 in	0.38 mm	0.015 "		30 Áin	0.76 Ám	Standard Tail	0.02 in	0.51 mm	Gold	Solder	0.031 in	0.79 mm	0.041 in	1.04 mm	3.81 mm	0.15 in	0.3 "	7.62 mm	0.46 mm	0.018 in	Beryllium Copper	0.56 mm
Mill-Max Manufacturing Corp. 0461-3-15-01-21-02-04-0	-55 C	125 °C	0.022 in	0.38 mm	0.015 "		100 µin	2.54 µm	Standard Tail	0.02 in	0.51 mm	Tin-Lead	Solder	0.031 in	0.79 mm	0.041 in	1.04 mm	3.81 mm	0.15 in	0.3 "	7.62 mm	0.46 mm	0.018 in	Beryllium Copper	0.56 mm
Mill-Max Manufacturing Corp. 0461-3-15-01-21-27-04-0	-55 C	125 °C	0.022 in	0.38 mm	0.015 "		30 Áin	0.76 Ám	Standard Tail	0.02 in	0.51 mm	Gold	Solder	0.031 in	0.79 mm	0.041 in	1.04 mm	3.81 mm	0.15 in	0.3 "	7.62 mm	0.46 mm	0.018 in	Beryllium Copper	0.56 mm
Mill-Max Manufacturing Corp. 0461-3-15-80-11-14-04-0	-55 C	125 °C	0.022 in	0.38 mm	0.015 "		10 Áin	0.25 Ám	Standard Tail	0.02 in	0.51 mm	Gold	Solder	0.031 in	0.79 mm	0.041 in	1.04 mm	3.81 mm	0.15 in	0.3 "	7.62 mm	0.46 mm	0.018 in	Beryllium Copper	0.56 mm
Mill-Max Manufacturing Corp. 0461-3-15-80-11-27-04-0	-55 C	125 °C	0.022 in	0.38 mm	0.015 "		30 Áin	0.76 Ám	Standard Tail	0.02 in	0.51 mm	Gold	Solder	0.031 in	0.79 mm	0.041 in	1.04 mm	3.81 mm	0.15 in	0.3 "	7.62 mm	0.46 mm	0.018 in	Beryllium Copper	0.56 mm
