311SM Series
Basic / Snap Action Switches Subminiature Basics
Manufacturer: Honeywell Sensing and Productivity Solutions
Catalog
Basic / Snap Action Switches Subminiature Basics
Basic / Snap Action Switches Subminiature Basics
Basic / Snap Action Switches Subminiature Basics
Basic / Snap Action Switches Subminiature Basics
| Part | Voltage Rating - AC | Mounting Type | Differential Travel | Differential Travel | Switch Function | Mechanical Life | Operating Temperature [Min] | Operating Temperature [Max] | Pretravel | Pretravel | Termination Style | Release Force | Circuit | Actuator Type | Overtravel [custom] | Overtravel [custom] | Current Rating (Amps) | Voltage Rating - DC | Operating Force | Operating Position | Operating Position | Operating Position [custom] | Operating Position [custom] | Operating Position [x] | Operating Position [x] | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Honeywell Sensing and Productivity Solutions | 250 V | Chassis Mount | 0.7 mm | 0.027 in | On-Mom | 10000000 Cycles | -55 C | 125 °C | 0.12 in | 3 mm | Solder Quick Connect - 0.110" (2.8mm) | 5.099 gf | SPDT | Lever Straight | 0.7 mm | 0.026 " | 5 A | 30 V | 30 gf | 8.5 mm | 0.335 " | |||||
Honeywell Sensing and Productivity Solutions | 125 V | Chassis Mount | 0.7 mm | 0.027 in | On-Mom | 10000000 Cycles | -55 C | 125 °C | 0.12 in | 3 mm | Solder Turret | 5.099 gf | SPDT | Lever Simulated Roller | 0.7 mm | 0.026 " | 100 mA | 30 V | 30 gf | 11.5 mm | 0.453 in | |||||
Honeywell Sensing and Productivity Solutions | 125 V | Chassis Mount | 0.5 mm | 0.02 in | On-Mom | 10000000 Cycles | -55 C | 125 °C | 0.085 in | 2.16 mm | Solder Quick Connect - 0.110" (2.8mm) | SPDT | Lever Straight | 0.5 mm | 0.02 " | 1 A | 30 V | 40 gf | 8.6 mm | 0.34 in | ||||||
Honeywell Sensing and Productivity Solutions | 250 V | Chassis Mount | 2.8 mm | 0.11 in | On-Mom | 10000000 Cycles | -55 C | 125 °C | 0.31 " | 7.9 mm | Solder Turret | 2.039 gfm | SPDT | Lever Straight | 1.45 mm | 0.057 " | 5 A | 30 V | 15 gf | 0.28 in | 7.1 mm | |||||
Honeywell Sensing and Productivity Solutions | 250 V | Chassis Mount | 0.5 mm | 0.02 in | On-Mom | 10000000 Cycles | -55 C | 125 °C | 0.085 in | 2.16 mm | Solder Turret | SPDT | Lever Simulated Roller | 0.45 mm | 0.018 " | 5 A | 30 V | 40 gf | 11.7 mm | 0.46 in | ||||||
Honeywell Sensing and Productivity Solutions | 250 V | Chassis Mount | 0.7 mm | 0.027 in | On-Mom | 10000000 Cycles | -55 C | 125 °C | 0.12 in | 3 mm | Solder Turret | 5.099 gf | SPDT | Lever Straight | 0.7 mm | 0.026 " | 5 A | 30 V | 30 gf | 8.5 mm | 0.335 " | |||||
Honeywell Sensing and Productivity Solutions | 125 V | Chassis Mount | 0.5 mm | 0.02 in | On-Mom | 10000000 Cycles | -55 C | 125 °C | 0.085 in | 2.16 mm | Solder Quick Connect - 0.110" (2.8mm) | SPDT | Lever Simulated Roller | 0.45 mm | 0.018 " | 1 A | 30 V | 40 gf | 11.7 mm | 0.46 in | ||||||
Honeywell Sensing and Productivity Solutions | 125 V | Chassis Mount | 0.5 mm | 0.02 in | On-Mom | 10000000 Cycles | -55 C | 125 °C | 0.085 in | 2.16 mm | Solder Quick Connect - 0.110" (2.8mm) | SPDT | Lever Roller | 0.45 mm | 0.018 " | 100 mA | 30 V | 40 gf | 14.2 mm | 0.56 in | ||||||
Honeywell Sensing and Productivity Solutions | 250 V | Chassis Mount | 0.5 mm | 0.02 in | On-Mom | 10000000 Cycles | -55 C | 125 °C | 0.085 in | 2.16 mm | Quick Connect | SPDT | Lever Roller | 0.45 mm | 0.018 " | 5 A | 30 V | 40 gf | 14.2 mm | 0.56 in | 0.058 in | |||||
Honeywell Sensing and Productivity Solutions | 125 V | Chassis Mount | 0.33 mm | 0.013 in | On-Mom | 10000000 Cycles | -55 C | 125 °C | 0.085 in | 2.16 mm | Solder Turret | 3.059 gf | SPDT | Lever Roller | 0.45 mm | 0.018 " | 1 A | 30 V | 16 gf | 14.2 mm | 0.56 in |
