284512 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

TERM BLOCK HDR 24POS 90DEG 3.5MM

Part	Color	Mounting Type	Current - UL	Contact Mating Finish	Insulation Height	Insulation Height	Material Flammability Rating	Header Orientation	Number of Positions	Voltage - UL	Contact Tail Length	Contact Tail Length	Termination Style	Type	Pitch [x]	Pitch [x]	Operating Temperature [Min]	Operating Temperature [Max]	Number of Levels	Contact Material	Positions Per Level	Number of Positions
TE Connectivity Raychem Cable Protection 2-284512-4	Green	Through Hole	11 A	Tin	7.3 mm	0.287 in	UL94 V-0	90° Right Angle	24	300 V	3.4 mm	0.134 in	Solder	Header Male Pins Shrouded (4 Side)	3.5 mm	0.138 in	-40 °C	110 °C	1	Phosphor Bronze
TE Connectivity Raychem Cable Protection 1-284512-3	Green	Through Hole	11 A	Tin	7.3 mm	0.287 in	UL94 V-0	90° Right Angle	13	300 V	3.4 mm	0.134 in	Solder	Header Male Pins Shrouded (4 Side)	3.5 mm	0.138 in	-40 °C	110 °C	1	Phosphor Bronze	13
TE Connectivity Raychem Cable Protection 1-284512-4	Green	Through Hole	11 A	Tin	7.3 mm	0.287 in	UL94 V-0	90° Right Angle	14	300 V	3.4 mm	0.134 in	Solder	Header Male Pins Shrouded (4 Side)	3.5 mm	0.138 in	-40 °C	110 °C	1	Phosphor Bronze	14
TE Connectivity Raychem Cable Protection 284512-5	Green	Through Hole	11 A	Tin	7.3 mm	0.287 in	UL94 V-0	90° Right Angle		300 V	3.4 mm	0.134 in	Solder	Header Male Pins Shrouded (4 Side)	3.5 mm	0.138 in	-40 °C	110 °C	1	Phosphor Bronze	5
TE Connectivity Raychem Cable Protection 284512-9	Green	Through Hole	11 A	Tin	7.3 mm	0.287 in	UL94 V-0	90° Right Angle	9	300 V	3.4 mm	0.134 in	Solder	Header Male Pins Shrouded (4 Side)	3.5 mm	0.138 in	-40 °C	110 °C	1	Phosphor Bronze	9
TE Connectivity Raychem Cable Protection 1-284512-9	Green	Through Hole	11 A	Tin	7.3 mm	0.287 in	UL94 V-0	90° Right Angle	19	300 V	3.4 mm	0.134 in	Solder	Header Male Pins Shrouded (4 Side)	3.5 mm	0.138 in	-40 °C	110 °C	1	Phosphor Bronze	19
TE Connectivity Raychem Cable Protection 2-284512-0	Green	Through Hole	11 A	Tin	7.3 mm	0.287 in	UL94 V-0	90° Right Angle	20	300 V	3.4 mm	0.134 in	Solder	Header Male Pins Shrouded (4 Side)	3.5 mm	0.138 in	-40 °C	110 °C	1	Phosphor Bronze	20
TE Connectivity Raychem Cable Protection 284512-4	Green	Through Hole	11 A	Tin	7.3 mm	0.287 in	UL94 V-0	90° Right Angle	4	300 V	3.4 mm	0.134 in	Solder	Header Male Pins Shrouded (4 Side)	3.5 mm	0.138 in	-40 °C	110 °C	1	Phosphor Bronze	4
TE Connectivity Raychem Cable Protection 1-284512-6	Green	Through Hole	11 A	Tin	7.3 mm	0.287 in	UL94 V-0	90° Right Angle		300 V	3.4 mm	0.134 in	Solder	Header Male Pins Shrouded (4 Side)	3.5 mm	0.138 in	-40 °C	110 °C	1	Phosphor Bronze	16	16
TE Connectivity Raychem Cable Protection 284512-3	Green	Through Hole	11 A	Tin	7.3 mm	0.287 in	UL94 V-0	90° Right Angle		300 V	3.4 mm	0.134 in	Solder	Header Male Pins Shrouded (4 Side)	3.5 mm	0.138 in	-40 °C	110 °C	1	Phosphor Bronze	3
