HM1F42 Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
METRAL RCT RA PF 4X12
| Part | Material Flammability Rating | Color | Number of Positions Loaded | Mounting Type | Contact Finish | Pitch [x] | Pitch [x] | Features | Termination | Connector Type | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Voltage Rating | Operating Temperature [Min] | Operating Temperature [Max] | Connector Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (FCI) | |||||||||||||||||
Amphenol ICC (FCI) | UL94 V-0 | Natural | All | Board Edge Right Angle Through Hole | Gold | 0.079 in | 2 mm | Board Guide Spacer | Press-Fit | Receptacle Female Sockets | 48 | 30 Áin | 0.76 Ám | ||||
 Amphenol ICC (FCI) | UL94 V-0 | Natural | All | Board Edge Right Angle Through Hole | Gold | 0.079 in | 2 mm | Board Guide Spacer | Solder | Receptacle Female Sockets | 48 | 29.5 µin | 0.75 µm | 1000 VDC | -55 C | 85 °C | High Speed |
Amphenol ICC (FCI) | UL94 V-0 | Natural | All | Board Edge Right Angle Through Hole | Gold | 0.079 in | 2 mm | Board Guide Spacer | Solder | Receptacle Female Sockets | 48 | 29.5 µin | 0.75 µm | 1000 VDC | -55 C | 85 °C | High Speed |
Amphenol ICC (FCI) | Natural | Board Edge Right Angle Through Hole | Gold | 0.079 in | 2 mm | Board Guide Spacer | Solder | Receptacle Female Sockets | 48 | 29.5 µin | 0.75 µm | High Speed | |||||
Amphenol ICC (FCI) | UL94 V-0 | Natural | All | Board Edge Right Angle Through Hole | Gold | 0.079 in | 2 mm | Board Guide Spacer | Press-Fit | Receptacle Female Sockets | 48 | 29.5 µin | 0.75 µm | 1000 VDC | -55 C | 105 ░C | High Speed |
