WRTP1A Series

Catalog

SWITCH ROCKER SPST 20A 125V

Part	Mechanical Life	Electrical Life	Voltage Rating - AC	Current Rating (Amps)	Switch Function	Mounting Type	Color - Actuator/Cap	Actuator Marking	Panel Cutout Dimensions [x]	Panel Cutout Dimensions [y]	Approval Agency	Voltage Rating - DC	Termination Style	Actuator Type	Ingress Protection	Circuit
Oslo Switch WRTP1A9M9	100000 Cycles	35000 Cycles	125 V	14 A 20 A	Off-On	Panel Mount Snap-In	Black	O I	27.43 mm	13.97 mm	CSA UL VDE	14 V	Quick Connect - 0.250" (6.3mm)	Concave (Curved)	IP64 - Dust Tight Water Resistant	SPST
Oslo Switch WRTP1A12M9-B	100000 Cycles	35000 Cycles	125 V	14 A 20 A	Off-On	Panel Mount Snap-In	Red	O I	27.43 mm	13.97 mm	CSA UL VDE	14 V	Quick Connect - 0.250" (6.3mm)	Concave (Curved)	IP64 - Dust Tight Water Resistant	SPST
Oslo Switch WRTP1A12M9	100000 Cycles	35000 Cycles	125 V	14 A 20 A	Off-On	Panel Mount Snap-In	Red	O I	27.43 mm	13.97 mm	CSA UL VDE	14 V	Quick Connect - 0.250" (6.3mm)	Concave (Curved)	IP64 - Dust Tight Water Resistant	SPST
