KMT40 Series
Manufacturer: TDK Corporation
Beta
⌘K
AC/DC PCB MOUNT POWER SUPPLY (PSU), MEDICAL, 3 OUTPUT, 40 W, 5 V, 5 A, 12 V
| Part | Line Regulation [custom] | Line Regulation [custom] | Weight [diameter] | Weight [diameter] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Efficiency | Standard Number | Current - Output (Max) | Mounting Type | Type | Features | Approval Agency | Number of Outputs | Voltage - Input [Max] | Voltage - Input [Min] | Applications | Package / Case | Voltage - Output 1 | Power (Watts) | Operating Temperature [Max] | Operating Temperature [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TDK Corporation | 0.5 % | 5 % | 280.32 g | 0.618 lb | 1.06 in | 27 mm | 89 mm | 3.5 " | 2.5 " | 63.5 mm | 80 % | 60601-1 60950-1 62368-1 | 5 A 600 mA | Through Hole | Enclosed | Universal Input | CE EN IEC UL | 3 | 264 VAC 375 VDC | 90 VAC 100 V | Medical | 7-DIP Module | 5 V | 40 W | 70 °C | -25 °C |
