Surge Suppressors FLT_SEC_P_T1_3S_ 440/35_FM
Surge Suppressors FLT_SEC_P_T1_3S_ 440/35_FM
| Part | Type | Overload Protection | Approval Agency | Region Utilized | Housing Material | Voltage - Protection Rating (VPR) | Voltage - Continuous Operating (Max) (MCOV) [Max] | Current - Discharge (Max) (8/20µS) [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Form | Number of Poles | Current - Discharge (Nom) (8/20µS) | Voltage - Protection Level (VP) (2416) | Current - Short Circuit Rating (SCCR) | Mounting Type | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | PDU Surge Protector Type 1 Type 2 | Fuse Holder | cUL cULus cUR EAC UL UR | International | Plastic | 3 kV | 440 VAC | 50 kA | 80 °C | -40 C | Base + Module | 1 | 35 kA | 4.5 kV | 50 kA | DIN Rail | Remote Signaling Contacts Visual Life Indicator |
 Phoenix Contact | PDU Surge Protector Type 1 Type 2 | Fuse Holder | CB CCA cUL cUR EAC IECEE CB Scheme KEMA-KEUR UL UR | International | Plastic | 1.8 kV | 440 VAC | 50 kA | 80 °C | -40 C | Base + Module | 1 | 35 kA | 2.5 kV | 50 kA | DIN Rail | Remote Signaling Contacts Visual Life Indicator |
 Phoenix Contact | PDU Surge Protector Type 1 Type 2 | Fuse Holder | CCA cUL cULus cUR EAC IECEE CB Scheme KEMA-KEUR UL UR | International | Plastic | 3 kV | 440 VAC | 50 kA | 80 °C | -40 C | Base + Module | 1 | 35 kA | 2.5 kV | 50 kA | DIN Rail | Remote Signaling Contacts Visual Life Indicator |
