PKE331 Series
Manufacturer: Flex Power Modules
Beta
⌘K
ISOLATED DC/DC CONVERTERS - THROUGH HOLE INPUT 9 - 36 V 12 V, 2.5 A / 30 W
| Part | Voltage - Input (Min) [Min] | Applications | Approval Agency | Operating Temperature [Min] | Operating Temperature [Max] | Control Features | Mounting Type | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Voltage - Input (Max) [Max] | Type | Voltage - Isolation | Number of Outputs | Power (Watts) | Standard Number | Voltage - Output 1 | Efficiency | Features | Package / Case | Current - Output (Max) [Max] | Size / Dimension [z] | Size / Dimension [y] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Flex Power Modules | 9 V | ITE (Commercial) | CB CSA IEC TUV UL | -40 °C | 110 °C | Active Low Enable | Through Hole | 25.4 mm | 11.4 mm | 25.4 mm | 1 " | 1 in | 0.45 in | 36 V | Isolated Module | 1.5 kV | 1 | 30 Watts | 62368-1 | 12 V | 92 % | Adjustable Output Remote On/Off | Sixteenth Brick | 2.5 A | ||
Flex Power Modules | 9 V | ITE (Commercial) | CB CSA IEC TUV UL | -40 °C | 110 °C | Active Low Enable | Through Hole | 25.4 mm | 1 " | 1 in | 0.43 in | 36 V | Isolated Module | 1.5 kV | 1 | 30 Watts | 62368-1 | 48 V | 92 % | Adjustable Output Remote On/Off | 6-DIP Module | 625 mA | 10.8 mm | 25.4 mm | ||
Flex Power Modules | 9 V | ITE (Commercial) | CB CSA IEC TUV UL | -40 °C | 110 °C | Active Low Enable | Through Hole | 25.4 mm | 1 " | 1 in | 0.43 in | 36 V | Isolated Module | 1.5 kV | 1 | 30 Watts | 62368-1 | 15 V | 92 % | Adjustable Output Remote On/Off | 6-DIP Module | 2 A | 10.8 mm | 25.4 mm | ||
Flex Power Modules | 9 V | ITE (Commercial) | CB CSA IEC TUV UL | -40 °C | 110 °C | Active Low Enable | Through Hole | 25.4 mm | 1 " | 1 in | 0.43 in | 36 V | Isolated Module | 1.5 kV | 1 | 30 Watts | 62368-1 | 24 V | 90 % | Adjustable Output Remote On/Off | 6-DIP Module | 1.25 A | 10.8 mm | 25.4 mm | ||
 Flex Power Modules | 9 V | ITE (Commercial) | CB CSA IEC TUV UL | -40 °C | 110 °C | Active Low Enable | Through Hole | 25.4 mm | 1 " | 1 in | 0.43 in | 36 V | Isolated Module | 1.5 kV | 1 | 25 W | 62368-1 | 54 V | 91 % | Adjustable Output Remote On/Off | 6-DIP Module | 463 mA | 10.8 mm | 25.4 mm | ||
Flex Power Modules | 9 V | ITE (Commercial) | CB CSA IEC TUV UL | -40 °C | 110 °C | Active Low Enable | Through Hole | 25.4 mm | 1 " | 1 in | 0.43 in | 36 V | Isolated Module | 1.5 kV | 1 | 30 Watts | 62368-1 | 5 V | 90 % | Adjustable Output Remote On/Off | 6-DIP Module | 6 A | 10.8 mm | 25.4 mm | ||
Flex Power Modules | 9 V | ITE (Commercial) | CB CSA IEC TUV UL | -40 °C | 110 °C | Active Low Enable | Through Hole | 25.4 mm | 1 " | 1 in | 0.43 in | 36 V | Isolated Module | 1.5 kV | 1 | 23 Watts | 62368-1 | 3.3 V | 88 % | Adjustable Output Remote On/Off | 6-DIP Module | 7 A | 10.8 mm | 25.4 mm |
