3402.0004 Series
Manufacturer: SCHURTER Inc.
Beta
⌘K
FUSE CHIP FAST ACTING 0.1A 63V SMD SOLDER PAD 7.4 X 3.1 X 2.6MM THERMOPLASTIC BAG CSA/UL
| Part | Melting I˛t | Operating Temperature [Min] | Operating Temperature [Max] | Current Rating (Amps) | Package / Case | Mounting Type | Melting I²t | Response Time | Fuse Type | Voltage Rating - DC | Breaking Capacity @ Rated Voltage | Voltage Rating - AC | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SCHURTER Inc. | 0.00067 | -55 C | 125 °C | 100 mA | 2-SMD J-Lead | Surface Mount | 0.00067 I²t | Fast Blow | Board Mount (Cartridge Style Excluded) | 63 VDC | 50 A | 63 V | 0.122 in | 0.102 in | 2.6 mm | 7.4 mm | 0.291 in | 3.1 mm |
SCHURTER Inc. | 0.00067 | -55 C | 125 °C | 100 mA | 2-SMD J-Lead | Surface Mount | 0.00067 I²t | Fast Blow | Board Mount (Cartridge Style Excluded) | 63 VDC | 50 A | 63 V | 0.122 in | 0.102 in | 2.6 mm | 7.4 mm | 0.291 in | 3.1 mm |
