431113 Series
Manufacturer: Curtis Industries
Beta
⌘K
CONN BARRIER STRP 19CIRC 0.438"
| Part | Mounting Type | Operating Temperature | Material Flammability Rating | Terminal Screw Material | Material - Insulation | Current Rating (Amps) | Voltage Rating | Wire Gauge [Max] | Wire Gauge [Min] | Number of Rows | Bottom Termination | Top Termination | Number of Circuits | Number of Wire Entries | Pitch [x] | Pitch [x] | Barrier Type | Terminal Block Type | Number of Wire Entries [custom] | Number of Circuits [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Curtis Industries | Through Hole | 105 C | UL94 V-0 | Stainless Steel | Polypropylene (PP) | 20 A | 600 V | 22 AWG | 12 AWG | 1 | PC Pin | Screws | 19 | 19 | 0.438 in | 11.12 mm | 2 Wall (Dual) | Barrier Block | ||
Curtis Industries | Through Hole | 105 C | UL94 V-0 | Stainless Steel | Polypropylene (PP) | 20 A | 600 V | 22 AWG | 12 AWG | 1 | PC Pin | Screws | 7 | 0.438 in | 11.12 mm | 2 Wall (Dual) | Barrier Block | 7 | ||
Curtis Industries | Through Hole | 105 C | UL94 V-0 | Stainless Steel | Polypropylene (PP) | 20 A | 600 V | 22 AWG | 12 AWG | 1 | PC Pin | Screws | 24 | 0.438 in | 11.12 mm | 2 Wall (Dual) | Barrier Block | |||
 Curtis Industries | Through Hole | 105 C | UL94 V-0 | Stainless Steel | Polypropylene (PP) | 20 A | 600 V | 22 AWG | 12 AWG | 1 | PC Pin | Screws | 9 | 0.438 in | 11.12 mm | 2 Wall (Dual) | Barrier Block | 9 | ||
Curtis Industries | Through Hole | 105 C | UL94 V-0 | Stainless Steel | Polypropylene (PP) | 20 A | 600 V | 22 AWG | 12 AWG | 1 | PC Pin | Screws | 10 | 10 | 0.438 in | 11.12 mm | 2 Wall (Dual) | Barrier Block | ||
Curtis Industries | Through Hole | 105 C | UL94 V-0 | Stainless Steel | Polypropylene (PP) | 20 A | 600 V | 22 AWG | 12 AWG | 1 | PC Pin | Screws | 6 | 6 | 0.438 in | 11.12 mm | 2 Wall (Dual) | Barrier Block | ||
Curtis Industries | Through Hole | 105 C | UL94 V-0 | Stainless Steel | Polypropylene (PP) | 20 A | 600 V | 22 AWG | 12 AWG | 1 | PC Pin | Screws | 4 | 4 | 0.438 in | 11.12 mm | 2 Wall (Dual) | Barrier Block | ||
Curtis Industries | Through Hole | 105 C | UL94 V-0 | Stainless Steel | Polypropylene (PP) | 20 A | 600 V | 22 AWG | 12 AWG | 1 | PC Pin | Screws | 14 | 14 | 0.438 in | 11.12 mm | 2 Wall (Dual) | Barrier Block | ||
Curtis Industries | Through Hole | 105 C | UL94 V-0 | Stainless Steel | Polypropylene (PP) | 20 A | 600 V | 22 AWG | 12 AWG | 1 | PC Pin | Screws | 22 | 22 | 0.438 in | 11.12 mm | 2 Wall (Dual) | Barrier Block | ||
 Curtis Industries | Through Hole | 105 C | UL94 V-0 | Stainless Steel | Polypropylene (PP) | 20 A | 600 V | 22 AWG | 12 AWG | 1 | PC Pin | Screws | 8 | 8 | 0.438 in | 11.12 mm | 2 Wall (Dual) | Barrier Block |
