COMBINATION LAYOUT D SUB CONNECTOR, 630C SERIES, DB-21W1, RECEPTACLE, 21 CONTACTS
| Part | Dielectric Material | Color | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Voltage Rating | Features | Shell Material, Finish | Connector Style | Number of Positions | Backset Spacing | Backset Spacing | Contact Finish | Current Rating (Amps) | Number of Rows [custom] | Shell Size, Connector Layout | Shell Size, Connector Layout | Contact Type | Connector Type | Flange Feature | Termination | Material Flammability Rating | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Number of Positions [x] | Number of Positions [custom] | Contact Finish Thickness | Flange Feature | Current Rating (Amps) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | Black | -55 C | 125 °C | Copper Alloy | 125 VDC | Board Lock Mounting Brackets | Nickel Plated Steel | Combo D-Sub | 21 | 9.4 mm | 0.37 in | Gold | 5 A 30 A | 2 | 21W1 B DB | 3 | Signal and Power | Receptacle Female Sockets | 4-40 | Solder | UL94 V-0 | 30 Áin | 0.76 Ám | Right Angle Through Hole | |||||
 EDAC Inc. | Polyester Thermoplastic | Black | -55 C | 125 °C | Copper Alloy | 125 VDC | Board Lock Mounting Brackets | Combo D-Sub | 9.4 mm | 0.37 in | Gold | 2 | 4 (DC C) - 21WA4 | Coax Signal | Receptacle Female Sockets | M3 | Solder | UL94 V-0 | Right Angle Through Hole | 17 | 4 | Flash | ||||||||
 EDAC Inc. | Polyester Thermoplastic | Black | -55 C | 125 °C | Copper Alloy | 125 VDC | Mounting Brackets | Nickel Plated Steel | Combo D-Sub | 21 | 9.4 mm | 0.37 in | Gold | 5 A 30 A | 2 | 4 (DC C) - 21WA4 | Signal and Power | Receptacle Female Sockets | Housing/Shell | Solder | UL94 V-0 | 30 Áin | 0.76 Ám | Right Angle Through Hole | 4-40 | |||||
 EDAC Inc. | Polyester Thermoplastic | Black | -55 C | 125 °C | Copper Alloy | 125 VDC | Board Lock Mounting Brackets | Nickel Plated Steel | Combo D-Sub | 9.4 mm | 0.37 in | Gold | 2 | 4 (DC C) - 21WA4 | Coax Signal | Receptacle Female Sockets | 4-40 | Solder | UL94 V-0 | 30 Áin | 0.76 Ám | Right Angle Through Hole | 17 | 4 | ||||||
 EDAC Inc. | Polyester Thermoplastic | Black | -55 C | 125 °C | Copper Alloy | 125 VDC | Mounting Brackets | Combo D-Sub | 21 | 9.4 mm | 0.37 in | Gold | 5 A 40 A | 2 | 21W1 B DB | 3 | Signal and Power | Receptacle Female Sockets | Housing/Shell | Solder | UL94 V-0 | Right Angle Through Hole | Flash | 4-40 | ||||||
 EDAC Inc. | Polyester Thermoplastic | Black | -55 C | 125 °C | Copper Alloy | 125 VDC | Mounting Brackets | Nickel Plated Steel | Combo D-Sub | 21 | 9.4 mm | 0.37 in | Gold | 5 A 40 A | 2 | 21W1 B DB | 3 | Signal and Power | Receptacle Female Sockets | Housing/Shell | Solder | UL94 V-0 | Right Angle Through Hole | Flash | 4-40 | |||||
 EDAC Inc. | Polyester Thermoplastic | Black | -55 C | 125 °C | Copper Alloy | 125 VDC | Board Lock Mounting Brackets | Combo D-Sub | 21 | 9.4 mm | 0.37 in | Gold | 5 A 30 A | 2 | 4 (DC C) - 21WA4 | Signal and Power | Receptacle Female Sockets | Housing/Shell (M3) | Solder | UL94 V-0 | 30 Áin | 0.76 Ám | Right Angle Through Hole | |||||||
 EDAC Inc. | Polyester Thermoplastic | Black | -55 C | 125 °C | Copper Alloy | 125 VDC | Board Lock Mounting Brackets | Nickel Plated Steel | Combo D-Sub | 21 | 9.4 mm | 0.37 in | Gold | 2 | 4 (DC C) - 21WA4 | Signal and Power | Receptacle Female Sockets | Housing/Shell (M3) | Solder | UL94 V-0 | 30 Áin | 0.76 Ám | Right Angle Through Hole | 20A 5A | ||||||
 EDAC Inc. | Polyester Thermoplastic | Black | -55 C | 125 °C | Copper Alloy | 125 VDC | Mounting Brackets | Nickel Plated Steel | Combo D-Sub | 21 | 9.4 mm | 0.37 in | Gold | 2 | 21W1 B DB | 3 | Signal and Power | Receptacle Female Sockets | M3 | Solder | UL94 V-0 | 30 Áin | 0.76 Ám | Right Angle Through Hole | 10A 5A | |||||
 EDAC Inc. | Polyester Thermoplastic | Black | -55 C | 125 °C | Copper Alloy | 125 VDC | Combo D-Sub | 21 | 9.4 mm | 0.37 in | Gold | 2 | 4 (DC C) - 21WA4 | Signal and Power | Receptacle Female Sockets | Board Side (M3) | Solder | UL94 V-0 | 30 Áin | 0.76 Ám | Right Angle Through Hole | 20A 5A |
