10077239 Series

Catalog

CONN HEADER VERT 16POS 2.54MM

Part	Connector Type	Number of Positions	Number of Rows [custom]	Overall Contact Length	Overall Contact Length	Operating Temperature [Max]	Operating Temperature [Min]	Contact Finish - Mating	Termination	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Current Rating (Amps)	Insulation Color	Contact Length - Post	Contact Length - Post	Contact Shape	Contact Material	Fastening Type	Mounting Type	Contact Finish - Post	Insulation Height	Insulation Height	Material Flammability Rating	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Shrouding	Contact Type	Pitch - Mating	Pitch - Mating	Number of Positions Loaded	Contact Length - Mating	Contact Length - Mating	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Insulation Material
Amphenol ICC (FCI) 10077239-116LF	Header Breakaway	16	2	0.608 in	15.44 mm	130 °C	-65 ░C	Gold	Press-Fit Solder	0.76 Ám	30 Áin	3 A	Black	0.19 in	4.83 mm	Square	Phosphor Bronze	Push-Pull	Through Hole	Tin	0.1 in	2.54 mm	UL94 V-0	0.1 in	2.54 mm	Unshrouded	Male Pin	0.1 "	2.54 mm	All	8.08 mm	0.318 in
Amphenol ICC (FCI) 10077239-212LF	Header	12	2	0.608 in	15.44 mm	130 °C	-65 ░C	Gold	Press-Fit	0.38 µm	15 µin	3 A	Black	0.71 in	18.03 mm	Square	Phosphor Bronze	Push-Pull	Through Hole	Tin	0.1 in	2.54 mm	UL94 V-0	0.1 in	2.54 mm	Unshrouded	Male Pin	0.1 "	2.54 mm	All	8.08 mm	0.318 in	40 Áin	1.02 Ám	Polycyclohexylenedimethylene Terephthalate (PCT) Glass Filled
Amphenol ICC (FCI) 10077239-140LF	Header Breakaway	40	2	0.608 in	15.44 mm	130 °C	-65 ░C	Gold	Press-Fit Solder	0.76 Ám	30 Áin	3 A	Black	0.19 in	4.83 mm	Square	Phosphor Bronze	Push-Pull	Through Hole	Tin	0.1 in	2.54 mm	UL94 V-0	0.1 in	2.54 mm	Unshrouded	Male Pin	0.1 "	2.54 mm	All	8.08 mm	0.318 in
Amphenol ICC (FCI) 10077239-420LF	Header Breakaway	20	2	0.608 in	15.44 mm	130 °C	-65 ░C		Press-Fit Solder	3.05 µm	120 µin	3 A	Black	0.19 in	4.83 mm	Square	Phosphor Bronze	Push-Pull	Through Hole	Tin	0.1 in	2.54 mm	UL94 V-0	0.1 in	2.54 mm	Unshrouded	Male Pin	0.1 "	2.54 mm	All	8.08 mm	0.318 in
Amphenol ICC (FCI) 10077239-214LF	Header Breakaway	14	2	0.608 in	15.44 mm	130 °C	-65 ░C	Gold	Press-Fit Solder	0.38 µm	15 µin	3 A	Black	0.19 in	4.83 mm	Square	Phosphor Bronze	Push-Pull	Through Hole	Tin	0.1 in	2.54 mm	UL94 V-0	0.1 in	2.54 mm	Unshrouded	Male Pin	0.1 "	2.54 mm	All	8.08 mm	0.318 in
Amphenol ICC (FCI) 10077239-206LF	Header	6	2	0.608 in	15.44 mm	130 °C	-65 ░C	Gold	Press-Fit	0.38 µm	15 µin	3 A	Black	0.71 in	18.03 mm	Square	Phosphor Bronze	Push-Pull	Through Hole	Tin	0.1 in	2.54 mm	UL94 V-0	0.1 in	2.54 mm	Unshrouded	Male Pin	0.1 "	2.54 mm	All	8.08 mm	0.318 in	40 Áin	1.02 Ám	Polycyclohexylenedimethylene Terephthalate (PCT) Glass Filled
Amphenol ICC (FCI) 10077239-172LF	Header Breakaway	72	2	0.608 in	15.44 mm	130 °C	-65 ░C	Gold	Press-Fit Solder	0.76 Ám	30 Áin	3 A	Black	0.19 in	4.83 mm	Square	Phosphor Bronze	Push-Pull	Through Hole	Tin	0.1 in	2.54 mm	UL94 V-0	0.1 in	2.54 mm	Unshrouded	Male Pin	0.1 "	2.54 mm	All	8.08 mm	0.318 in
Amphenol ICC (FCI) 10077239-108LF	Header Breakaway	8	2	0.608 in	15.44 mm	130 °C	-65 ░C	Gold	Press-Fit Solder	0.76 Ám	30 Áin	3 A	Black	0.19 in	4.83 mm	Square	Phosphor Bronze	Push-Pull	Through Hole	Tin	0.1 in	2.54 mm	UL94 V-0	0.1 in	2.54 mm	Unshrouded	Male Pin	0.1 "	2.54 mm	All	8.08 mm	0.318 in
Amphenol ICC (FCI) 10077239-106TLF	Header Breakaway	6	2	0.608 in	15.44 mm	130 °C	-65 ░C	Gold	Press-Fit Solder	0.76 Ám	30 Áin	3 A	Black	0.19 in	4.83 mm	Square	Phosphor Bronze	Push-Pull	Through Hole	Tin	0.1 in	2.54 mm	UL94 V-0	0.1 in	2.54 mm	Unshrouded	Male Pin	0.1 "	2.54 mm	All	8.08 mm	0.318 in
Amphenol ICC (FCI) 10077239-120LF	Header Breakaway	20	2	0.608 in	15.44 mm	130 °C	-65 ░C	Gold	Press-Fit Solder	0.76 Ám	30 Áin	3 A	Black	0.19 in	4.83 mm	Square	Phosphor Bronze	Push-Pull	Through Hole	Tin	0.1 in	2.54 mm	UL94 V-0	0.1 in	2.54 mm	Unshrouded	Male Pin	0.1 "	2.54 mm	All	8.08 mm	0.318 in
