3028-1551 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
SLB / STRAIGHT PLUG FEMALE CLAMP
| Part | Voltage Rating | Body Material | Dielectric Material | Insertion Loss | Center Contact Plating | Mating Cycles | Body Finish | Operating Temperature [Min] | Operating Temperature [Max] | Cable Group | Impedance | Number of Ports | Connector Style | Shield Termination | Housing Color | Frequency - Max [Max] | Fastening Type | Connector Type | Center Contact Material | Mounting Type | Contact Termination | Mounting Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | 250 V | Brass | Polytetrafluoroethylene (PTFE) | 0.3 dB | Gold | 500 | Gold | -65 ░C | 165 °C | RG-178 | 50 Ohms | 1 | SLB | Clamp | Gold | 4 GHz | Snap-On | Female Socket Plug | Beryllium Copper | Panel Mount | Solder | Bulkhead - Front Side Nut |
 Radiall USA, Inc. | 335 V | Brass | Polytetrafluoroethylene (PTFE) | 0.3 dB | Gold | 500 | Gold | -65 ░C | 165 °C | RG-316 | 50 Ohms | 1 | SLB | Clamp | Gold | 4 GHz | Snap-On | Female Socket Plug | Beryllium Copper | Panel Mount | Solder | Bulkhead - Front Side Nut |
