BSA07 Series

Catalog

CONN PLG HSG FMALE 8POS INLINE

Part	Features	Contact Shape	Insert Material	Shielding	Operating Temperature (Min)	Operating Temperature (Max)	Housing Color	Type	Shell Finish	Mounting Type	Note	Fastening Type	Includes Total Count	Includes	Ingress Protection Description	Ingress Protection IP Rating	Number of Positions	Position Types	Material Flammability Rating	Connector Type	Shell Material	Orientation
TE Intercontec BSA078N00580235000	Backshell Cable Clamp Coupling Nut	Circular	Nylon 6/6 PA66 Polyamide	Shielded	-20 °C	130 °C	Silver	For Female Sockets	Nickel	Free Hanging (In-Line)	Contacts Not Included	Push-Twist	3 pcs	Backshell Cable Clamp Connector	Dust Tight Water Resistant Waterproof	IP66 IP67	8	PE Power	UL94 V-0	Plug Housing	Zinc Die Cast	Keyed
TE Intercontec BSA078N00480235000	Backshell Cable Clamp Coupling Nut	Circular	Nylon 6/6 PA66 Polyamide	Shielded	-20 °C	130 °C	Silver	For Female Sockets	Nickel	Free Hanging (In-Line)	Contacts Not Included	Push-Twist	3 pcs	Backshell Cable Clamp Connector	Dust Tight Water Resistant Waterproof	IP66 IP67	8	PE Power	UL94 V-0	Plug Housing	Zinc Die Cast	Keyed
TE Intercontec BSA078N00590100000	Backshell Cable Clamp Coupling Nut	Circular	Nylon 6/6 PA66 Polyamide	Shielded	-20 °C	130 °C	Silver	For Female Sockets	Nickel	Free Hanging (In-Line)	Contacts Not Included	Push-Twist	3 pcs	Backshell Cable Clamp Connector	Dust Tight Water Resistant Waterproof	IP66 IP67	8	PE Power	UL94 V-0	Plug Housing	Zinc Die Cast	Keyed
TE Intercontec BSA078N00550235000	Backshell Cable Clamp Coupling Nut	Circular	Nylon 6/6 PA66 Polyamide	Shielded	-20 °C	130 °C	Silver	For Female Sockets	Nickel	Free Hanging (In-Line)	Contacts Not Included	Push-Twist	3 pcs	Backshell Cable Clamp Connector	Dust Tight Water Resistant Waterproof	IP66 IP67	8	PE Power	UL94 V-0	Plug Housing	Zinc Die Cast	Keyed
TE Intercontec BSA078N00420100000	Backshell Cable Clamp Coupling Nut	Circular	Nylon 6/6 PA66 Polyamide	Shielded	-20 °C	130 °C	Silver	For Female Sockets	Nickel	Free Hanging (In-Line)	Contacts Not Included	Push-Twist	3 pcs	Backshell Cable Clamp Connector	Dust Tight Water Resistant Waterproof	IP66 IP67	8	PE Power	UL94 V-0	Plug Housing	Zinc Die Cast	Keyed
TE Intercontec BSA078N00580100000	Backshell Cable Clamp Coupling Nut	Circular	Nylon 6/6 PA66 Polyamide	Shielded	-20 °C	130 °C	Silver	For Female Sockets	Nickel	Free Hanging (In-Line)	Contacts Not Included	Push-Twist	3 pcs	Backshell Cable Clamp Connector	Dust Tight Water Resistant Waterproof	IP66 IP67	8	PE Power	UL94 V-0	Plug Housing	Zinc Die Cast	Keyed
