QS30A Series
Manufacturer: BANNER ENGINEERING
Beta
⌘K
PHOTOELECTRIC SENSOR, QS30 SERIES, WORLD-BEAM, ADJUSTABLE-FIELD, 300MM, NPN / PNP, 10-30V, CONNECTOR
| Part | Ingress Protection | Adjustment Type | Operating Temperature [Max] | Operating Temperature [Min] | Response Time | Sensing Method | Connection Method | Sensing Distance [Min] | Sensing Distance [Max] | Light Source | Voltage - Supply [Min] | Voltage - Supply [Max] | Output Configuration | Cable Length | Cable Length | Sensing Distance | Sensing Distance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | Adjustable | 55 °C | -10 °C | 1 ms | Background Suppression | Connector | 1.97 in 50 mm | 11.81 in 300 mm | LED | 10 VDC | 30 VDC | NPN PNP | ||||
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | Adjustable | 55 °C | -10 °C | 1 ms | Background Suppression | Cable | 1.97 in 50 mm | 11.81 in 300 mm | LED | 10 VDC | 30 VDC | NPN PNP | 78.74 " | 2 m | ||
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | Adjustable | 60 °C | -20 ░C | Background Suppression | Connector | LED | 10 VDC | 30 VDC | Dark-ON/Light-ON NPN/PNP | 23.622 " | 60 cm | |||||
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | 70 °C | -20 ░C | Through-Beam | Connector | Infrared (875nm) | 10 VDC | 30 VDC | NPN/PNP - Light-ON | 698.82 ft | 213 m | ||||||
 BANNER ENGINEERING | IP69K NEMA 6P | 70 °C | -20 ░C | Through-Beam | Connector | Infrared LED | 10 VDC | 30 VDC | NPN/PNP - Light-ON | 698.82 ft | 213 m | ||||||
 BANNER ENGINEERING | IP67 NEMA 6P | 70 °C | -20 ░C | 100 ms | Through-Beam | Connector | Infrared LED | 10 VDC | 30 VDC | NPN - Light-ON | 698.82 ft | 213 m | |||||
BANNER ENGINEERING | IP67 NEMA 6P | 70 °C | -20 ░C | Through-Beam | Cable | Infrared LED | 10 VDC | 30 VDC | NPN/PNP - Light-ON | 78.74 " | 2 m | 698.82 ft | 213 m |
