CL1M Series
Manufacturer: Souriau-Sunbank by Eaton
Catalog
CONN RCPT HSNG MALE 4POS PNL MNT
| Part | Shell Size - Insert | Operating Temperature [Max] | Operating Temperature [Min] | Fastening Type | Material Flammability Rating | Orientation | Mounting Feature | Type | Note | Number of Positions | Shielding | Connector Type | Contact Size | Contact Type | Insert Material | Ingress Protection | Contact Shape | Shell Material | Housing Color | Shell Size - Insert [Max] | Shell Size - Insert [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Souriau-Sunbank by Eaton | 1-1 | 125 °C | -40 °C | Twist Latch | UL94 V-0 | Keyed | Flange | For Male Pins | Contacts Not Included | 4 | Unshielded | Receptacle Housing | 16 | Crimp and Solder Cup | Thermoplastic | IP67 - Dust Tight Waterproof | Circular | Thermoplastic Halogen Free | Black | ||
 Souriau-Sunbank by Eaton | 125 °C | -40 °C | Twist Latch | UL94 V-0 | Keyed | Flange | For Male Pins | Contacts Not Included | 14 | Unshielded | Receptacle Housing | 20 | Crimp and Solder Cup | Thermoplastic | IP40 | Circular | Thermoplastic Halogen Free | Black | 2 | 2 | |
 Souriau-Sunbank by Eaton | 4-1 | 125 °C | -40 °C | Twist Latch | UL94 V-0 | Keyed | Flange | For Male Pins | Contacts Not Included | 26 | Unshielded | Receptacle Housing | 16 | Crimp and Solder Cup | Thermoplastic | IP67 - Dust Tight Waterproof | Circular | Thermoplastic Halogen Free | Black | ||
Souriau-Sunbank by Eaton | 1-1 | 125 °C | -40 °C | Twist Latch | UL94 V-0 | Keyed | Flange | For Male Pins | Contacts Not Included | 4 | Unshielded | Receptacle Housing | 16 | Crimp and Solder Cup | Thermoplastic | IP40 | Circular | Thermoplastic Halogen Free | Black | ||
 Souriau-Sunbank by Eaton | 125 °C | -40 °C | Twist Latch | UL94 V-0 | Keyed | Flange | For Male Pins | Contacts Not Included | 9 | Unshielded | Receptacle Housing | 16 | Crimp and Solder Cup | Thermoplastic | IP67 - Dust Tight Waterproof | Circular | Thermoplastic Halogen Free | Black | |||
 Souriau-Sunbank by Eaton | 125 °C | -40 °C | Twist Latch | UL94 V-0 | Keyed | Flange | For Male Pins | Contacts Not Included | 9 | Unshielded | Receptacle Housing | 20 | Crimp and Solder Cup | Thermoplastic | IP68 - Dust Tight Waterproof | Circular | Thermoplastic Halogen Free | Black | 2 | 1 | |
 Souriau-Sunbank by Eaton | 125 °C | -40 °C | Twist Latch | UL94 V-0 | Keyed | Flange | For Male Pins | Contacts Not Included | 40 | Unshielded | Receptacle Housing | 16 | Crimp and Solder Cup | Thermoplastic | IP68 - Dust Tight Waterproof | Circular | Thermoplastic Halogen Free | Black | 4 | 2 | |
 Souriau-Sunbank by Eaton | 125 °C | -40 °C | Twist Latch | UL94 V-0 | Keyed | Flange | For Male Pins | Contacts Not Included | 9 | Unshielded | Receptacle Housing | 20 | Crimp and Solder Cup | Thermoplastic | IP40 | Circular | Thermoplastic Halogen Free | Black | 2 | 1 | |
 Souriau-Sunbank by Eaton | 4-1 | 125 °C | -40 °C | Twist Latch | UL94 V-0 | Keyed | Flange | For Male Pins | Contacts Not Included | 26 | Unshielded | Receptacle Housing | 16 | Crimp and Solder Cup | Thermoplastic | IP68 - Dust Tight Waterproof | Circular | Thermoplastic Halogen Free | Black | ||
 Souriau-Sunbank by Eaton | 125 °C | -40 °C | Twist Latch | UL94 V-0 | Keyed | Flange | For Male Pins | Contacts Not Included | 9 | Unshielded | Receptacle Housing | 16 | Crimp and Solder Cup | Thermoplastic | IP68 - Dust Tight Waterproof | Circular | Thermoplastic Halogen Free | Black |
