SFM-1440 Series
Manufacturer: East Electronics
Beta
⌘K
BUZZER 5V 0.575" L X 0.575" W TH
| Part | Operating Mode | Sound Pressure Level (SPL) | Frequency | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Termination | Voltage Range [Max] | Voltage Range [Min] | Mounting Type | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Voltage - Rated | Current - Supply | Operating Temperature [Max] | Operating Temperature [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 East Electronics | Continuous | 75 dB | 4 kHz | 0.169 in | 4.3 mm | PC Pins | 20 V | 1 | Through Hole | 14.6 mm | 0.575 in | 0.575 in | 14.6 mm | 5 V | 2 mA | 85 °C | -20 ░C |
