845-088 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 88POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Contact Material | Read Out | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Color | Termination | Pitch | Pitch | Features | Number of Positions/Bay/Row | Mounting Type | Gender | Card Type | Operating Temperature [Max] | Operating Temperature [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Dual | Gold | 0.25 Ám | 10 Áin | 88 | Green | Solder | 0.1 " | 2.54 mm | Card Extender | 44 | Board Edge Straddle Mount | Female | Non Specified - Dual Edge | 125 °C | -40 C |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.128 " | Flush Mount Side Opening Unthreaded | 3.25 mm | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Dual | Gold | 0.25 Ám | 10 Áin | 88 | Green | Solder | 0.1 " | 2.54 mm | Card Extender | 44 | Board Edge Straddle Mount | Female | Non Specified - Dual Edge | 125 °C | -40 C |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Dual | Gold | 0.25 Ám | 10 Áin | 88 | Green | Solder | 0.1 " | 2.54 mm | 44 | Through Hole | Female | Non Specified - Dual Edge | 125 °C | -40 C | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | M3 Threaded Insert Top Mount Opening | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Dual | Gold | 0.25 Ám | 10 Áin | 88 | Green | Wire Wrap | 0.1 " | 2.54 mm | 44 | Through Hole | Female | Non Specified - Dual Edge | 125 °C | -40 C | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Dual | Gold | 0.25 Ám | 10 Áin | 88 | Green | Wire Wrap | 0.1 " | 2.54 mm | 44 | Through Hole | Female | Non Specified - Dual Edge | 125 °C | -40 C | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Flush Mount M3 Threaded Insert Top Opening | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Dual | Gold | 0.25 Ám | 10 Áin | 88 | Green | Wire Wrap | 0.1 " | 2.54 mm | 44 | Through Hole | Female | Non Specified - Dual Edge | 125 °C | -40 C | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | M3 Threaded Insert Top Mount Opening | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Dual | Gold | 0.25 Ám | 10 Áin | 88 | Green | Solder | 0.1 " | 2.54 mm | 44 | Right Angle Through Hole | Female | Non Specified - Dual Edge | 125 °C | -40 C | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | M3 Threaded Insert Top Mount Opening | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Dual | Gold | 0.25 Ám | 10 Áin | 88 | Green | Solder | 0.1 " | 2.54 mm | 44 | Through Hole | Female | Non Specified - Dual Edge | 125 °C | -40 C | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Flush Mount M3 Threaded Insert Top Opening | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Dual | Gold | 0.25 Ám | 10 Áin | 88 | Green | Wire Wrap | 0.1 " | 2.54 mm | 44 | Through Hole | Female | Non Specified - Dual Edge | 125 °C | -40 C | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | M3 Threaded Insert Top Mount Opening | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Dual | Gold | 0.25 Ám | 10 Áin | 88 | Green | Solder | 0.1 " | 2.54 mm | 44 | Through Hole | Female | Non Specified - Dual Edge | 125 °C | -40 C |
