Potter & Brumfield T9C Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
T9CP5A52-240
| Part | Coil Resistance | Relay Type | Contact Rating (Current) | Release Time | Coil Current | Mounting Type | Contact Material | Coil Voltage | Contact Form | Switching Voltage [Max] | Termination Style | Termination Style | Load - Max Switching [Max] | Coil Insulation | Operate Time | Must Operate Voltage | Must Release Voltage | Operating Temperature [Max] | Operating Temperature [Min] | Coil Type | Approval Agency | Load - Max Switching |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 11.5 kOhms | General Purpose | 30 A | 15 ms | 20.9 mA | Chassis Mount | Silver Cadmium Oxide (AgCdO) | 240 VAC/DC | SPDT (1 Form C) | 277 VAC | 0.187 in 0.25 in | Quick Connect | 8310 VA | Class F | 15 ms | 192 VAC | 24 VAC | 85 °C | -40 C | Non Latching | CSA UR VDE | |
 TE Connectivity AMP Connectors | 12 kOhms | General Purpose | 30 A | 15 ms | 20.9 mA | Chassis Mount | Silver Tin Oxide Indium Oxide (AgSnOInO) | 240 VAC/DC | SPST-NO (1 Form A) | 277 VAC | 0.187 in 0.25 in | Quick Connect | 8310 VA | Class F | 15 ms | 192 VAC | 24 VAC | 70 °C | -40 C | Non Latching | CSA UR VDE | |
 TE Connectivity AMP Connectors | General Purpose | 30 A | 15 ms | 66.7 mA | Chassis Mount | Silver Tin Oxide Indium Oxide (AgSnOInO) | 24 VAC | SPST-NO (1 Form A) | 277 VAC | 0.187 in 0.25 in | Quick Connect | 8310 VA | Class F | 15 ms | 19.2 VAC | 7.2 VAC | 70 °C | -40 C | Non Latching | CSA UR VDE | ||
 TE Connectivity AMP Connectors | General Purpose | 10 A | 15 ms | 42.9 mA | Chassis Mount | Silver Tin Oxide Indium Oxide (AgSnOInO) | 120 VAC | SPST-NC (1 Form B) | 277 VAC | 0.187 in 0.25 in | Quick Connect | Class F | 15 ms | 96 VAC | 12 VAC | 85 °C | -40 C | Non Latching | CSA UR VDE | 2770 VA | ||
 TE Connectivity AMP Connectors | General Purpose | 30 A | 15 ms | 13.3 mA | Chassis Mount | Silver Cadmium Oxide (AgCdO) | 110 VAC/DC | SPST-NO (1 Form A) | 277 VAC | 0.187 in 0.25 in | Quick Connect | 8310 VA | Class F | 15 ms | 88 VAC/DC | 33 VAC | 70 °C | -40 C | Non Latching | CSA UR VDE | ||
 TE Connectivity AMP Connectors | General Purpose | 20 A | 15 ms | 20.9 mA | Chassis Mount | Silver Tin Oxide (AgSnO) | 240 VAC/DC | SPDT (1 Form C) | 277 VAC | 0.187 in 0.25 in | Quick Connect | Class F | 15 ms | 192 VAC | 24 VAC | 85 °C | -40 C | Non Latching | CSA UR VDE | 5540 VA | ||
 TE Connectivity AMP Connectors | General Purpose | 20 A | 15 ms | Chassis Mount | Silver Cadmium Oxide (AgCdO) | 24 VAC | SPDT (1 Form C) | 277 VAC | 0.187 in 0.25 in | Quick Connect | Class F | 15 ms | 19.2 VAC | 2.4 VAC/DC | 85 °C | -40 C | Non Latching | CSA UR VDE | 5540 VA | |||
TE Connectivity AMP Connectors | General Purpose | 20 A | 15 ms | 42.9 mA | Chassis Mount | Silver Cadmium Oxide (AgCdO) | 120 VAC | SPDT (1 Form C) | 277 VAC | 0.187 in 0.25 in | Quick Connect | Class F | 15 ms | 96 VAC | 12 VAC | 85 °C | -40 C | Non Latching | CSA UR VDE | 5540 VA | ||
 TE Connectivity AMP Connectors | 11.5 kOhms | General Purpose | 30 A | 15 ms | 20.9 mA | Chassis Mount | Silver Cadmium Oxide (AgCdO) | 240 VAC/DC | SPST-NO (1 Form A) | 277 VAC | 0.187 in 0.25 in | Quick Connect | 8310 VA | Class F | 15 ms | 192 VAC | 24 VAC | 85 °C | -40 C | Non Latching | CSA UR VDE | |
 TE Connectivity AMP Connectors | 144 Ohms | General Purpose | 20 A | 15 ms | 66.7 mA | Chassis Mount | Silver Tin Oxide Indium Oxide (AgSnOInO) | 24 VAC | SPDT (1 Form C) | 277 VAC | 0.187 in 0.25 in | Quick Connect | Class F | 15 ms | 19.2 VAC | 7.2 VAC | 70 °C | -40 C | Non Latching | CSA UR VDE | 5540 VA |
