Fixed Terminal Blocks GMKDS 3/ 6-7.62
Fixed Terminal Blocks GMKDS 3/ 6-7.62
| Part | Housing Material | Screw Thread | Torque - Screw [Max] | Torque - Screw [Min] | Torque - Screw [Min] | Torque - Screw [Max] | Mounting Type | Number of Levels | Current | Positions Per Level | Pitch | Pitch | Mating Orientation | Wire Termination | Wire Gauge [Max] | Wire Gauge [Min] | Features | Voltage | Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | Polyamide (PA) Nylon | M3 | 0.6 Nm | 4.4 Lb-In | 0.5 Nm | 5.3 Lb-In | Through Hole | 1 | 15 A | 6 | 0.3 in | 7.62 mm | Horizontal with Board | Screw - Rising Cage Clamp | 30 AWG | 12 AWG | Interlocking (Side) | 300 VDC | Green |
