8884MN Series

Catalog

CABLE 9CON 22AWG BLUE SHLD

Part	Shield Coverage	Shield Material	Conductor Material	Conductor Strand [custom]	Conductor Strand [custom]	Operating Temperature [Max]	Operating Temperature [Min]	Voltage	Length	Length	Cable Type	Number of Conductors	Features	Conductor Insulation	Jacket Color	Jacket (Insulation) Material	Ratings	Shield Type	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Usage	Wire Gauge	Length [x]	Length [x]
Belden Inc. 8884MN 0061000	100 %	Aluminum	Copper Tinned	34 AWG	19	80 °C	-20 ░C	300 VDC	304.8 m	1000 ft	Multi-Conductor	9	Drain Wire	Polypropylene (PP)	Blue	Poly-Vinyl Chloride (PVC)	UL Style 2937	Foil	5.51 mm	0.217 in	0.406 mm	0.016 in	Audio Control Instrumentation	22 AWG
Belden Inc. 8884MN 0041000	100 %	Aluminum	Copper Tinned	34 AWG	19	80 °C	-20 ░C	300 VDC	304.8 m	1000 ft	Multi-Conductor	9	Drain Wire	Polypropylene (PP)	Yellow	Poly-Vinyl Chloride (PVC)	UL Style 2937	Foil	5.51 mm	0.217 in	0.406 mm	0.016 in	Audio Control Instrumentation	22 AWG
Belden Inc. 8884MN 004100	100 %	Aluminum	Copper Tinned	34 AWG	19	80 °C	-20 ░C	300 VDC			Multi-Conductor	9	Drain Wire	Polypropylene (PP)	Yellow	Poly-Vinyl Chloride (PVC)	UL Style 2937	Foil	5.51 mm	0.217 in	0.406 mm	0.016 in	Audio Control Instrumentation	22 AWG	100 ft	30.5 m
Belden Inc. 8884MN 006100	100 %	Aluminum	Copper Tinned	34 AWG	19	80 °C	-20 ░C	300 VDC			Multi-Conductor	9	Drain Wire	Polypropylene (PP)	Blue	Poly-Vinyl Chloride (PVC)	UL Style 2937	Foil	5.51 mm	0.217 in	0.406 mm	0.016 in	Audio Control Instrumentation	22 AWG	100 ft	30.5 m
