19400101 Series
Manufacturer: HARTING
Beta
⌘K
HAN 10HPR-HSM1-SL-M50
| Part | Size | Style | Housing Color | Operating Temperature [Max] | Operating Temperature [Min] | Connector Type | Thread Size | Housing Material | Lock Location | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Features | Housing Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 HARTING | 10B | Side Entry | Black | 125 °C | -40 C | Hood | M50 | Aluminum Die Cast | Screw Locks on Hood | ||||||||
 HARTING | 10B | Top Entry | Black | 125 °C | -40 C | Base - Panel Mount | Aluminum Die Cast | Screw Locks on Hood | 106 mm | 4.626 " | 117.5 mm | 4.173 " | 6.89 in | 175 mm | Corrosion Resistant | ||
 HARTING | 10B | Side Entry | Black | 125 °C | -40 C | Base - Box Mount | M32 | Aluminum Die Cast | Screw Locks on Hood | Powder Coated | |||||||
 HARTING | 10B | Top Entry | Black | 125 °C | -40 C | Base - Panel Mount | Aluminum Die Cast | Screw Locks on Hood | Feed Through | Powder Coated |
