34 Series

Catalog

FIXED IND 68UH 350MA 1.05OHM SMD

Part	Tolerance	Current Rating (Amps)	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	DC Resistance (DCR) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Type	Shielding	Inductance	Mounting Type	DC Resistance (DCR)
Murata Electronics 34683C	20 %	350 mA	5.2 mm	0.205 "	0.205 "	5.2 mm	0.079 in	2 mm	1.05 Ohm	125 °C	-40 C	Nonstandard	Wirewound	Shielded	68 µH	Surface Mount
Murata Electronics 34152C	30 %	2.1 A	5.2 mm	0.205 "	0.205 "	5.2 mm	0.079 in	2 mm		125 °C	-40 C	Nonstandard	Wirewound	Shielded	1.5 µH	Surface Mount	40 mOhm
Murata Electronics 34332C	30 %	1.5 A	5.2 mm	0.205 "	0.205 "	5.2 mm	0.079 in	2 mm	80 mOhm	125 °C	-40 C	Nonstandard	Wirewound	Shielded	3.3 µH	Surface Mount
Murata Electronics 34334C	20 %	150 mA	5.2 mm	0.205 "	0.205 "	5.2 mm	0.079 in	2 mm	4.55 Ohm	125 °C	-40 C	Nonstandard	Wirewound	Shielded	330 µH	Surface Mount
Murata Electronics 34222C	30 %	1.7 A	5.2 mm	0.205 "	0.205 "	5.2 mm	0.079 in	2 mm	50 mOhm	125 °C	-40 C	Nonstandard	Wirewound	Shielded	2.2 µH	Surface Mount
Murata Electronics 34333C	20 %	480 mA	5.2 mm	0.205 "	0.205 "	5.2 mm	0.079 in	2 mm	560 mOhm	125 °C	-40 C	Nonstandard	Wirewound	Shielded	33 µH	Surface Mount
Murata Electronics 34103C	20 %	800 mA	5.2 mm	0.205 "	0.205 "	5.2 mm	0.079 in	2 mm		125 °C	-40 C	Nonstandard	Wirewound	Shielded	10 µH	Surface Mount	200 mOhm
Murata Electronics 34473C	20 %	410 mA	5.2 mm	0.205 "	0.205 "	5.2 mm	0.079 in	2 mm	850 mOhm	125 °C	-40 C	Nonstandard	Wirewound	Shielded	47 µH	Surface Mount
Murata Electronics 34472C	30 %	1.3 A	5.2 mm	0.205 "	0.205 "	5.2 mm	0.079 in	2 mm		125 °C	-40 C	Nonstandard	Wirewound	Shielded	4.7 ÁH	Surface Mount	100 mOhm
Murata Electronics 34122C	30 %	2.5 A	5.2 mm	0.205 "	0.205 "	5.2 mm	0.079 in	2 mm	30 mOhm	125 °C	-40 C	Nonstandard	Wirewound	Shielded	1.2 µH	Surface Mount
