F24S1 Series
Manufacturer: MEAN WELL USA Inc.
Beta
⌘K
19MM/GN/LIGHT24V/MAINTAINED/1NO1
| Part | Circuit | Illumination Voltage (Nominal) | Switch Function | Ingress Protection | Voltage Rating - AC | Color - Actuator/Cap | Current Rating (Amps) | Voltage Rating - DC | Termination Style | Actuator Type | Panel Cutout Dimensions [diameter] | Type | Illumination Type, Color | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 MEAN WELL USA Inc. | DPST-NO/NC | 12 VDC | Off-On On-Off | IP67 - Dust Tight Waterproof | 125 V | Green | 1A 4A | 30 V | Solder Lug | Button Flush Round | 19 mm | Anti-Vandal Illuminated | Green LED | 50 °C | -25 °C | Panel Mount Rear |
