SJ1-25 Series
Manufacturer: Same Sky (Formerly CUI Devices)
Beta
⌘K
CONN JACK STEREO 2.5MM SMD R/A
| Part | Number of Positions/Contacts [custom] | Number of Positions/Contacts [custom] | Shielding | Connector Type | Features | Actual Diameter [diameter] | Actual Diameter [diameter] | Operating Temperature [Max] | Operating Temperature [Min] | Industry Recognized Mating Diameter | Industry Recognized Mating Diameter | Industry Recognized Mating Diameter | Signal Lines | Termination | Mounting Type | Internal Switch(s) | Gender | Contact Material - Plating | Housing Material | Mating Length/Depth | Mating Length/Depth | Contact Material | Voltage - Rated | Current Rating (Amps) | Body Color | Internal Switch(s) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Same Sky (Formerly CUI Devices) | 4 | 3 | Unshielded | Phone Jack | Board Guide | 2.6 mm | 0.102 in | 85 °C | -25 °C | 2.5 mm | 0.094 " | 3 /32" | Stereo (3 Conductor TRS) | Solder | Right Angle Surface Mount | Single Switch | Female | |||||||||
 Same Sky (Formerly CUI Devices) | 5 | 3 | Unshielded | Phone Jack | Board Guide | 2.6 mm | 0.102 in | 85 °C | -25 °C | 2.5 mm | 0.094 " | 3 /32" | Stereo (3 Conductor TRS) | Solder | Right Angle Surface Mount | Two Switches | Female | Gold | Nylon 6T Polyamide (PA6T) | 11 mm | 0.433 in | Copper Alloy | 12 VDC | 1 A | Black | |
Same Sky (Formerly CUI Devices) | 5 | 3 | Unshielded | Phone Jack | Board Guide | 2.6 mm | 0.102 in | 85 °C | -25 °C | 2.5 mm | 0.094 " | 3 /32" | Stereo (3 Conductor TRS) | Solder | Right Angle Surface Mount | Two Switches | Female | |||||||||
 Same Sky (Formerly CUI Devices) | 4 | 3 | Unshielded | Phone Jack | Board Guide | 2.6 mm | 0.102 in | 85 °C | -25 °C | 2.5 mm | 0.094 " | 3 /32" | Stereo (3 Conductor TRS) | Solder | Right Angle Surface Mount | Single Switch | Female | Gold | Nylon 6T Polyamide (PA6T) | 11 mm | 0.433 in | Copper Alloy | 12 VDC | 1 A | Black | |
 Same Sky (Formerly CUI Devices) | 3 | 3 | Unshielded | Phone Jack | Board Guide | 2.6 mm | 0.102 in | 85 °C | -25 °C | 2.5 mm | 0.094 " | 3 /32" | Stereo (3 Conductor TRS) | Solder | Right Angle Surface Mount | Female | ||||||||||
Same Sky (Formerly CUI Devices) | 3 | 3 | Unshielded | Phone Jack | Board Guide | 2.6 mm | 0.102 in | 85 °C | -25 °C | 2.5 mm | 0.094 " | 3 /32" | Stereo (3 Conductor TRS) | Solder | Right Angle Surface Mount | Female | Gold | Nylon 6T Polyamide (PA6T) | 11 mm | 0.433 in | Beryllium Copper Brass | 12 VDC | 1 A | Black | ||
Same Sky (Formerly CUI Devices) | 4 | 3 | Unshielded | Phone Jack | Board Guide | 2.6 mm | 0.102 in | 85 °C | -25 °C | 2.5 mm | 0.094 " | 3 /32" | Stereo (3 Conductor TRS) | Solder | Right Angle Surface Mount | Single Switch | Female | |||||||||
Same Sky (Formerly CUI Devices) | 4 | 3 | Unshielded | Phone Jack | Board Guide | 2.6 mm | 0.102 in | 85 °C | -25 °C | 2.5 mm | 0.094 " | 3 /32" | Stereo (3 Conductor TRS) | Solder | Right Angle Surface Mount | Single Switch | Female | Gold | Nylon 6T Polyamide (PA6T) | 11 mm | 0.433 in | Brass Copper Alloy | 12 VDC | 1 A | Black | |
 Same Sky (Formerly CUI Devices) | 4 | 3 | Unshielded | Phone Jack | Board Guide | 2.6 mm | 0.102 in | 85 °C | -25 °C | 2.5 mm | 0.094 " | 3 /32" | Stereo (3 Conductor TRS) | Solder | Right Angle Surface Mount | Single Switch | Female | Gold | 11 mm | 0.433 in | Brass Copper Alloy | 12 VDC | 1 A | Black |
