RSF100 Series
Manufacturer: Sensata-Crydom
Beta
⌘K
SENSOR LEVEL SWITCH SINGLE FLOAT
| Part | Material - Housing & Prism | Type | Output Type | Mounting Type | Current | Voltage Rating | Operating Temperature [Max] | Operating Temperature [Min] | Output Configuration | Minimum Liquid Specific Gravity [Min] |
|---|---|---|---|---|---|---|---|---|---|---|
 Sensata-Crydom | Polyphenylene Sulphide (PPS) | Liquid | Switch (Single Float) | M16x2 Thread Panel Mount | 600 mA | 120 VDC 240 VAC | 120 °C | -10 °C | SPST-NO | |
 Sensata-Crydom | Polypropylene (PP) | Liquid | Switch (Single Float) | M16x2 Thread Panel Mount | 1 A | 300 VDC 300 VAC | 100 °C | -20 ░C | SPST-NO | |
 Sensata-Crydom | Polypropylene (PP) | Liquid | Switch (Single Float) | M16x2 Thread Panel Mount | 600 mA | 120 VDC 240 VAC | 100 °C | -20 ░C | SPST-NO | |
 Sensata-Crydom | Nylon | Liquid | Switch (Single Float) | M16x2 Thread Panel Mount | 600 mA | 120 VDC 240 VAC | SPST-NO | |||
 Sensata-Crydom | Polyvinylidene Fluoride (PVDF) | Liquid | Switch (Single Float) | M16x2 Thread Panel Mount | 600 mA | 120 VDC 240 VAC | 105 ░C | -10 °C | SPST-NC/NO | 0.95 |
 Sensata-Crydom | Polyphenylene Sulphide (PPS) | Liquid | Switch (Single Float) | M16x2 Thread Panel Mount | 600 mA | 120 VDC 240 VAC | 120 °C | -10 °C | SPST-NO | |
 Sensata-Crydom | Polypropylene (PP) | Liquid | Switch (Single Float) | M16x2 Thread Panel Mount | 600 mA | 120 VDC 240 VAC | 100 °C | -20 ░C | SPST-NO | |
 Sensata-Crydom | Polyphenylene Sulphide (PPS) | Liquid | Switch (Single Float) | M16x2 Thread Panel Mount | 1 A | 300 VDC 300 VAC | 120 °C | -10 °C | SPST-NO | |
 Sensata-Crydom | Polypropylene (PP) | Liquid | Switch (Single Float) | M16x2 Thread Panel Mount | 1 A | 300 VDC 300 VAC | 100 °C | -20 ░C | SPST-NO | |
 Sensata-Crydom | Polyvinylidene Fluoride (PVDF) | Liquid | Switch (Single Float) | M16x2 Thread Panel Mount | 1 A | 300 VDC 300 VAC | 105 ░C | -10 °C | SPST-NC/NO | 0.95 |
