BCR129 Series

Manufacturer: INFINEON

Catalog

TRANS PREBIAS NPN 50V SOT323

Part	Supplier Device Package	Current - Collector (Ic) (Max) [Max]	Resistor - Base (R1)	Voltage - Collector Emitter Breakdown (Max) [Max]	Package / Case	Mounting Type	Power - Max [Max]	Frequency - Transition	DC Current Gain (hFE) (Min) @ Ic, Vce [Min]	Current - Collector Cutoff (Max) [Max]	Transistor Type	Vce Saturation (Max) @ Ib, Ic	Grade	Qualification
INFINEON BCR129WH6327XTSA1	PG-SOT323	100 mA	10 kOhms	50 V	SC-70 SOT-323	Surface Mount	250 mW	150 MHz	120	100 nA	NPN - Pre-Biased	300 mV
INFINEON BCR129WE6327HTSA1	PG-SOT323	100 mA	10 kOhms	50 V	SC-70 SOT-323	Surface Mount	250 mW	150 MHz	120	100 nA	NPN - Pre-Biased	300 mV
INFINEON BCR129SH6327XTSA1	PG-SOT363-PO	100 mA		50 V	6-VSSOP SC-88 SOT-363	Surface Mount	250 mW	150 MHz	120		2 NPN - Pre-Biased (Dual)	300 mV
INFINEON BCR129FE6327	PG-SOT23-3-3	100 mA	10 kOhms	50 V	SC-59 SOT-23-3 TO-236-3	Surface Mount	200 mW	150 MHz	120	100 nA	NPN - Pre-Biased	300 mV	Automotive	AEC-Q101
