HXJ Series
Manufacturer: Chemi-Con
Beta
⌘K
ALUMINUM ORGANIC POLYMER CAPACITORS 390UF 35V ESR=35
| Part | Surface Mount Land Size [x] | Surface Mount Land Size [y] | Surface Mount Land Size [x] | Surface Mount Land Size [y] | Lifetime @ Temp. | Mounting Type | Ratings | ESR (Equivalent Series Resistance) | Ripple Current @ High Frequency | Ripple Current @ Low Frequency | Operating Temperature [Min] | Operating Temperature [Max] | Size / Dimension [diameter] | Size / Dimension [diameter] | Tolerance | Voltage - Rated | Type | Package / Case | Applications | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Capacitance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Chemi-Con | 8.3 mm 10.3 mm | 8.3 mm 10.3 mm | 0.327 in 0.406 " | 0.327 in 0.406 in | 4000 Hrs | Surface Mount | AEC-Q200 | 20 mOhms | 2.8 A | 420 mA | -55 C | 125 °C | 0.394 in | 10 mm | 20 % | 35 V | Hybrid | Radial Can - SMD | Automotive | 0.413 " | 10.5 mm | 390 µF |
 Chemi-Con | 8.3 mm | 8.3 mm | 0.327 in | 0.327 in | 4000 Hrs | Surface Mount | AEC-Q200 | 20 mOhms | 2 A | 300 mA | -55 C | 125 °C | 0.315 in | 8 mm | 20 % | 16 V | Hybrid | Radial Can - SMD | Automotive | 0.413 " | 10.5 mm | 470 µF |
