Switching Power Supplies 120W 90-264Vin 12Vout 12.5A
Switching Power Supplies 120W 90-264Vin 12Vout 12.5A
| Part | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Power (Watts) | Efficiency | Current - Output 1 | Features | Voltage - Output 1 | Mounting Type | Applications | Operating Temperature [Min] | Operating Temperature [Max] | Type | Number of Outputs | Approval Agency | Voltage - Input [Max] | Voltage - Input [Min] | Voltage - Isolation | Size / Dimension [y] | Size / Dimension [z] | Minimum Load Required |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Recom Power | 105 mm | 35 mm | 1.38 in | 62 mm | 4.13 in | 2.44 " | 125 W 150 W | 91 % | 3.125 A | PFC Universal Input | 48 V | Chassis Mount | ITE (Commercial) | -30 °C | 70 °C | Conformal Coated Enclosed | 1 | CB CE cURus EAC | 264 VAC | 90 VAC | 3000 V | |||
 Recom Power | 101.6 mm | 1.18 in | 4 " | 2 in | 125 W 150 W | 91 % | 12.5 A | PFC Universal Input | 12 V | Chassis Mount | ITE (Commercial) | -30 °C | 70 °C | Open Frame Conformal Coated | 1 | CB CE cURus EAC | 264 VAC | 90 VAC | 3000 V | 50.8 mm | 30 mm | |||
Recom Power | 101.6 mm | 1.18 in | 4 " | 2 in | 125 W 150 W | 91 % | 3.125 A | PFC Universal Input | 48 V | Chassis Mount | ITE (Commercial) | -30 °C | 70 °C | Open Frame Conformal Coated | 1 | CB CE cURus EAC | 264 VAC | 90 VAC | 3000 V | 50.8 mm | 30 mm | |||
 Recom Power | 105 mm | 35 mm | 1.38 in | 62 mm | 4.13 in | 2.44 " | 125 W 150 W | 91 % | 12.5 A | PFC Universal Input | 12 V | Chassis Mount | ITE (Commercial) | -30 °C | 70 °C | Conformal Coated Enclosed | 1 | CB CE cURus EAC | 264 VAC | 90 VAC | 3000 V | |||
 Recom Power | 101.6 mm | 1.18 in | 4 " | 2 in | 125 W 150 W | 91 % | 6.25 A | PFC Universal Input | 24 V | Chassis Mount | ITE (Commercial) | -30 °C | 70 °C | Open Frame Conformal Coated | 1 | CB CE cURus EAC | 264 VAC | 90 VAC | 3000 V | 50.8 mm | 30 mm | |||
Recom Power | 105 mm | 35 mm | 1.38 in | 62 mm | 4.13 in | 2.44 " | 125 W 150 W | 91 % | 6.25 A | PFC Universal Input | 24 V | Chassis Mount | ITE (Commercial) | -30 °C | 70 °C | Conformal Coated Enclosed | 1 | CB CE cURus EAC | 264 VAC | 90 VAC | 3000 V |
