SP Series

Manufacturer: YAGEO

Catalog

NTC THERMISTORS NTC, 25MM, 3OHM 15A, +/-20% BOX

Part	Approval Agency	Tolerance	R @ 25°C	Diameter [diameter]	Diameter [diameter]	R @ Current	Lead Spacing	Lead Spacing	Current - Steady State Max	Current - Steady State Max [Max]
YAGEO N25SP003M-F	TUV UL	20 %	3 Ohms	0.984 in	25 mm	59 mOhms	0.295 in	7.5 mm	15 A
YAGEO N25SP1R5L-F	TUV UL	15 %	1.5 Ohms	0.984 in	25 mm	36 mOhms	0.295 in	7.5 mm	15 A
YAGEO N20SP001M	TUV UL	20 %	1 Ohms	0.787 in	20 mm	51 mOhms	0.295 in	7.5 mm	10 A
YAGEO N13SP018L-F	TUV UL	15 %	18 Ohms	0.512 in	13 mm	391 mOhms	0.295 in	7.5 mm		3 A
YAGEO N25SP6R8L	TUV UL	15 %	6.8 Ohms	0.984 in	25 mm	73 mOhms	0.295 in	7.5 mm		10.5 A
YAGEO N08SP008M-F	TUV UL	20 %	8 Ohms	0.315 in	8 mm	250 mOhms	0.197 "	5 mm		3 A
YAGEO N25SP1R5M	TUV UL	20 %	1.5 Ohms	0.984 in	25 mm	36 mOhms	0.295 in	7.5 mm	15 A
YAGEO N25SP1R5L	TUV UL	15 %	1.5 Ohms	0.984 in	25 mm	36 mOhms	0.295 in	7.5 mm	15 A
YAGEO N15SP1R3M	TUV UL	20 %	1.3 Ohms	0.591 in	15 mm	59 mOhms	0.295 in	7.5 mm		8 A
YAGEO N13SP2R5M	TUV UL	20 %	2.5 Ohms	0.512 in	13 mm	94 mOhms	0.295 in	7.5 mm	6 A
