1SNK8 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
AUT SNK PLUGGABLE
| Part | Housing Material | Wire Strip Length | Ingress Protection | Insulation Height | Insulation Height | Plug Wire Entry | Number of Positions | Voltage - IEC | Wire Gauge or Range - mm² [Max] | Wire Gauge or Range - mm² [Min] | Voltage - UL | Current - IEC | Mounting Type | Type | Current - UL | Color | Number of Levels | Wire Gauge or Range - AWG [Max] | Wire Gauge or Range - AWG [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Termination Style | Positions Per Level |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Polyamide (PA) Nylon | 10.5 mm | IP20 | 1.55 in | 39.37 mm | 180 ° | 2 | 800 V | 4 mm² | 0.2 mm² | 300 V | 29 A | Free Hanging (In-Line) | Plug Female Sockets | 28 A | Gray | 1 | 24 AWG | 10 AWG | -55 C | 110 °C | Screw - Rising Cage Clamp | 2 |
