TD Series

Headers & Wire Housings .100" Double Row Screw Machine Terminal Strip

Manufacturer: Eaton - Electronics Division

Catalog

Headers & Wire Housings .100" Double Row Screw Machine Terminal Strip

Catalog

Headers & Wire Housings .100" Double Row Screw Machine Terminal Strip

Part	Shielding	Current Rating (Amps)	Inductance Frequency - Test	Material - Core	Current - Saturation (Isat)	Tolerance	Inductance	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Package / Case	Mounting Type	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Operating Temperature [Max]	Operating Temperature [Min]	DC Resistance (DCR)	Type	Accessory Type	For Use With/Related Products	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
Eaton - Electronics Division SD12-6R2-R	Shielded	1.21 A	100 kHz	Ferrite	1.08 A	20 %	6.2 µH	1.2 mm	0.047 "	Nonstandard	Surface Mount	5.2 mm	0.205 "	0.205 "	5.2 mm	85 °C	-40 C	169.9 mOhm	Drum Core Wirewound
Eaton - Electronics Division TD3-D																				Base	Fuseholder
Eaton - Electronics Division SD10-470-R	Shielded	337 mA	100 kHz	Ferrite	349 mA	20 %	47 µH			Nonstandard	Surface Mount	5.2 mm	0.205 "	0.205 "	5.2 mm	85 °C	-40 C	1.47 Ohm	Drum Core Wirewound			0.039 in	1 mm
Eaton - Electronics Division SD25-681-R	Shielded	262 mA	100 kHz	Ferrite	154 mA	20 %	680 µH			Nonstandard	Surface Mount	5.2 mm	0.205 "	0.205 "	5.2 mm	85 °C	-40 C	3.88 Ohm	Drum Core Wirewound			0.098 in	2.5 mm
Eaton - Electronics Division SD20-150-R	Shielded	1.25 A	100 kHz	Ferrite	718 mA	20 %	15 µH			Nonstandard	Surface Mount	5.2 mm	0.205 "	0.205 "	5.2 mm	85 °C	-40 C	165.5 mOhm	Drum Core Wirewound				0.079 in	2 mm
Eaton - Electronics Division SD18-821-R	Shielded	0.145 A	100 kHz	Ferrite	113 mA	20 %	820 µH			Nonstandard	Surface Mount	5.2 mm	0.205 "	0.205 "	5.2 mm	85 °C	-40 C	12.35 Ohm	Drum Core Wirewound			0.071 in	1.8 mm
