11047-10 Series

Manufacturer: CNC Tech

Catalog

HOOK-UP STRND 10AWG BLUE

Part	Length	Length	Ratings	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Voltage	Conductor Material	Conductor Strand [custom]	Conductor Strand [custom]	Jacket Color	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Cable Type	Jacket (Insulation) Material	Operating Temperature [Min]	Operating Temperature [Max]	Wire Gauge
CNC Tech 11047-10-1-0500-005-1-TS	152.4 m	500 ft	UL Style 11047	0.09 inches	2.29 mm	600 V	Copper Tinned	19	0.0092 "	Blue	0.009 in	0.23 mm	Hook-Up	Polyphenylene Ether (PPE)	-10 °C	105 ░C	10 AWG
CNC Tech 11047-10-1-0500-007-1-TS	152.4 m	500 ft	UL Style 11047	0.09 inches	2.29 mm	600 V	Copper Tinned	19	0.0092 "	Green	0.009 in	0.23 mm	Hook-Up	Polyphenylene Ether (PPE)	-10 °C	105 ░C	10 AWG
CNC Tech 11047-10-1-0500-003-1-TS	152.4 m	500 ft	UL Style 11047	0.09 inches	2.29 mm	600 V	Copper Tinned	19	0.0092 "	Yellow	0.009 in	0.23 mm	Hook-Up	Polyphenylene Ether (PPE)	-10 °C	105 ░C	10 AWG
CNC Tech 11047-10-1-0500-001-1-TS	152.4 m	500 ft	UL Style 11047	0.09 inches	2.29 mm	600 V	Copper Tinned	19	0.0092 "	Black	0.009 in	0.23 mm	Hook-Up	Polyphenylene Ether (PPE)	-10 °C	105 ░C	10 AWG
