TPC Series

Catalog

PLUGGABLE TERMINAL BLOCKS 7 POS 10.16MM PITCH PLUG 18-6 AWG SCREW

Part	Torque - Screw [Min]	Torque - Screw [Max]	Torque - Screw [Max]	Torque - Screw [Min]	Insulation Height	Insulation Height	Screw Size	Wire Strip Length	Housing Material	Material Flammability Rating	Current - IEC	Number of Positions	Voltage - IEC	Wire Gauge or Range - AWG [Max]	Wire Gauge or Range - AWG [Min]	Pitch	Pitch	Positions Per Level [custom]	Positions Per Level [custom]	Type	Termination Style	Mounting Type	Contact Mating Finish	Color	Plug Wire Entry	Number of Levels [custom]	Number of Levels [custom]	Current - UL	Wire Gauge or Range - mm² [Min] [custom]	Wire Gauge or Range - mm² [Max] [custom]
Phoenix Contact 1715222	15 Lb-In	1.8 Nm	15.9 Lb-In	1.7 Nm	2.024 in	51.4 mm	M4	18 mm	Polyamide (PA) Nylon	UL94 V-0	76 A	7	1 kV	20 AWG	4 AWG	10.16 mm	0.4 in	7	14	Plug Female Sockets	Screw - Rising Cage Clamp	Free Hanging (In-Line)	Silver	Green	180 °	1	2	60 A	0.75 mm²	16 mm²
