ADP2138 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

POWER MANAGEMENT IC DEVELOPMENT TOOLS EVALUATION BOARD

Part	Supplied Contents	Total Output Count	Output Type	Non-Isolated Output Count	Board Type	Current - Output	Frequency - Switching	Contents	Voltage - Output	Utilized IC / Part	Main Purpose	Voltage - Input (Minimum)	Voltage - Input (Maximum)	Regulator Topology	Function	Voltage - Input (Min)	Mounting Type	Topology	Package Name	Package Length	Package Width	Number of Outputs	Output Configuration	Synchronous Rectifier	Operating Temperature (Max)	Operating Temperature (Min)	Voltage - Output (Min/Fixed)	Package / Case	Voltage - Input (Max)
Analog Devices Inc./Maxim Integrated ADP2138CB-0.8EVALZ	Board(s)	1	Non-Isolated	1 count	Fully Populated	800 mA	3 MHz	Board	0.8 V	ADP2138	DC/DC Step Down	2.3 V	5.5 V	Buck
Analog Devices Inc./Maxim Integrated ADP2138ACBZ-1.8-R7			Fixed			800 mA	3 MHz								Step-Down	2.3 V	Surface Mount	Buck	6-WLCSP	1.03 mm	1.5 mm	1	Positive	Yes	85 °C	-40 °C	1.8 V	6-UFBGA WLCSP	5.5 V
Analog Devices Inc./Maxim Integrated ADP2138ACBZ-0.8-R7			Fixed			800 mA	3 MHz								Step-Down	2.3 V	Surface Mount	Buck	6-WLCSP	1.03 mm	1.5 mm	1	Positive	Yes	85 °C	-40 °C	0.8 V	6-UFBGA WLCSP	5.5 V
Analog Devices Inc./Maxim Integrated ADP2138CB-2.5EVALZ	Board(s)	1	Non-Isolated	1 count	Fully Populated	800 mA	3 MHz	Board	2.5 V	ADP2138	DC/DC Step Down	2.3 V	5.5 V	Buck
Analog Devices Inc./Maxim Integrated ADP2138CB-1.5EVALZ	Board(s)	1	Non-Isolated	1 count	Fully Populated	800 mA	3 MHz	Board	1.5 V	ADP2138	DC/DC Step Down	2.3 V	5.5 V	Buck
Analog Devices Inc./Maxim Integrated ADP2138ACBZ-3.3-R7			Fixed			800 mA	3 MHz								Step-Down	2.3 V	Surface Mount	Buck	6-WLCSP	1.03 mm	1.5 mm	1	Positive	Yes	85 °C	-40 °C	3.3 V	6-UFBGA WLCSP	5.5 V
Analog Devices Inc./Maxim Integrated ADP2138ACBZ-1.0-R7			Fixed			800 mA	3 MHz								Step-Down	2.3 V	Surface Mount	Buck	6-WLCSP	1.03 mm	1.5 mm	1	Positive	Yes	85 °C	-40 °C	1 V	6-UFBGA WLCSP	5.5 V
Analog Devices Inc./Maxim Integrated ADP2138CB-1.0EVALZ	Board(s)	1	Non-Isolated	1 count	Fully Populated	800 mA	3 MHz	Board	1 V	ADP2138	DC/DC Step Down	2.3 V	5.5 V	Buck
Analog Devices Inc./Maxim Integrated ADP2138ACBZ-3.0-R7			Fixed			800 mA	3 MHz								Step-Down	2.3 V	Surface Mount	Buck	6-WLCSP	1.03 mm	1.5 mm	1	Positive	Yes	85 °C	-40 °C	3 V	6-UFBGA WLCSP	5.5 V
Analog Devices Inc./Maxim Integrated ADP2138ACBZ-2.5-R7			Fixed			800 mA	3 MHz								Step-Down	2.3 V	Surface Mount	Buck	6-WLCSP	1.03 mm	1.5 mm	1	Positive	Yes	85 °C	-40 °C	2.5 V	6-UFBGA WLCSP	5.5 V
