155220 Series

Catalog

CONN HEADER SMD 20POS 2MM

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Finish - Mating	Insulation Height [z]	Insulation Height [z]	Row Spacing - Mating	Row Spacing - Mating	Insulation Color	Number of Rows [custom]	Termination	Contact Material	Material Flammability Rating	Mounting Type	Style	Number of Positions	Contact Type	Contact Length - Mating	Contact Length - Mating	Number of Positions Loaded	Shrouding	Connector Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Pitch - Mating	Pitch - Mating	Current Rating (Amps)	Features	Contact Shape	Contact Finish - Post	Fastening Type	Operating Temperature [Min]	Operating Temperature [Max]	Contact Length - Post [x]	Contact Length - Post [x]	Contact Length - Post	Contact Length - Post	Insulation Height	Insulation Height
3M Electronic Specialty 155220-2200-RB-WE	200 µin	5.08 µm	Gold	10.8 mm	0.425 in	2 mm	0.079 in	Black	2	Solder	Copper Alloy	UL94 V-0	Surface Mount	Board to Cable/Wire	20	Male Pin	3.81 mm	0.15 in	All	Shrouded - 4 Wall	Header	0.76 Ám	30 Áin	0.079 "	2 mm	1.25 A	Keying Slot Pick and Place	Square	Tin	Latch Lock/Eject Hooks	-55 C	105 ░C
3M Electronic Specialty 155220-6302-RB	200 µin	5.08 µm	Gold	10.8 mm	0.425 in	2 mm	0.079 in	Black	2	Solder	Copper Alloy	UL94 V-0	Through Hole	Board to Cable/Wire	20	Male Pin	3.81 mm	0.15 in	All	Shrouded - 4 Wall	Header	0.76 Ám	30 Áin	0.079 "	2 mm	1.25 A	Keying Slot	Square	Tin	Latch Lock/Eject Hooks	-55 C	105 ░C	0.112 in	2.84 mm
3M Electronic Specialty 155220-2300-RB	200 µin	5.08 µm	Gold	10.8 mm	0.425 in	2 mm	0.079 in	Black	2	Solder	Copper Alloy	UL94 V-0	Surface Mount	Board to Cable/Wire	20	Male Pin	3.81 mm	0.15 in	All	Shrouded - 4 Wall	Header	0.76 Ám	30 Áin	0.079 "	2 mm	1.25 A	Keying Slot	Square	Tin	Latch Lock/Eject Hooks	-55 C	105 ░C
3M Electronic Specialty 155220-6202-RB	200 µin	5.08 µm	Gold	10.8 mm	0.425 in	2 mm	0.079 in	Black	2	Solder	Copper Alloy	UL94 V-0	Through Hole	Board to Cable/Wire	20	Male Pin	3.81 mm	0.15 in	All	Shrouded - 4 Wall	Header	0.76 Ám	30 Áin	0.079 "	2 mm	1.25 A	Keying Slot	Square	Tin	Latch Lock/Eject Hooks	-55 C	105 ░C	0.112 in	2.84 mm
3M Electronic Specialty 155220-6402-RB	200 µin	5.08 µm	Gold	10.8 mm	0.425 in	2 mm	0.079 in	Black	2	Solder	Copper Alloy	UL94 V-0	Through Hole	Board to Cable/Wire	20	Male Pin	3.81 mm	0.15 in	All	Shrouded - 4 Wall	Header	0.76 Ám	30 Áin	0.079 "	2 mm	1.25 A	Keying Slot	Square	Tin	Latch Lock/Eject Hooks	-55 C	105 ░C	0.112 in	2.84 mm
3M Electronic Specialty 155220-6202-RA	200 µin	5.08 µm	Gold	10.8 mm	0.425 in	2 mm	0.079 in	Black	2	Solder	Copper Alloy	UL94 V-0	Through Hole	Board to Cable/Wire	20	Male Pin	3.81 mm	0.15 in	All	Shrouded - 4 Wall	Header	0.25 µm	10 µin	0.079 "	2 mm	1.25 A	Keying Slot	Square	Tin	Latch Lock/Eject Hooks	-55 C	105 ░C	0.112 in	2.84 mm
3M Electronic Specialty 155220-2200-RB	200 µin	5.08 µm	Gold	10.8 mm	0.425 in	2 mm	0.079 in	Black	2	Solder	Copper Alloy	UL94 V-0	Surface Mount	Board to Cable/Wire	20	Male Pin	3.81 mm	0.15 in	All	Shrouded - 4 Wall	Header	0.76 Ám	30 Áin	0.079 "	2 mm	1.25 A	Keying Slot	Square	Tin	Latch Lock/Eject Hooks	-55 C	105 ░C
3M Electronic Specialty 155220-6302-RA	200 µin	5.08 µm	Gold	10.8 mm	0.425 in	2 mm	0.079 in	Black	2	Solder	Copper Alloy	UL94 V-0	Through Hole	Board to Cable/Wire	20	Male Pin	3.81 mm	0.15 in	All	Shrouded - 4 Wall	Header	0.25 µm	10 µin	0.079 "	2 mm	1.25 A	Keying Slot	Square	Tin	Latch Lock/Eject Hooks	-55 C	105 ░C	0.112 in	2.84 mm
3M Electronic Specialty 155220-2300-RB-WE	200 µin	5.08 µm	Gold	10.8 mm	0.425 in	2 mm	0.079 in	Black	2	Solder	Copper Alloy	UL94 V-0	Surface Mount	Board to Cable/Wire	20	Male Pin	3.81 mm	0.15 in	All	Shrouded - 4 Wall	Header	0.76 Ám	30 Áin	0.079 "	2 mm	1.25 A	Keying Slot Pick and Place	Square	Tin	Latch Lock/Eject Hooks	-55 C	105 ░C
3M Electronic Specialty 155220-5303-RB	200 µin	5.08 µm	Gold			2 mm	0.079 in	Black	2	Solder	Copper Alloy	UL94 V-0	Right Angle Through Hole	Board to Cable/Wire	20	Male Pin	3.81 mm	0.15 in	All	Shrouded - 4 Wall	Header	0.76 Ám	30 Áin	0.079 "	2 mm	1.25 A	Keying Slot	Square	Tin	Latch Lock/Eject Hooks	-55 C	105 ░C			3.94 mm	0.155 "	6.28 mm	0.247 "
