SJ-25 Series
Manufacturer: Same Sky (Formerly CUI Devices)
Beta
⌘K
CONN JACK STEREO 2.5MM R/A
| Part | Number of Positions/Contacts [custom] | Number of Positions/Contacts [custom] | Connector Type | Industry Recognized Mating Diameter | Industry Recognized Mating Diameter | Industry Recognized Mating Diameter | Internal Switch(s) | Operating Temperature [Min] | Operating Temperature [Max] | Signal Lines | Termination | Gender | Shielding | Mounting Type | Actual Diameter [diameter] | Actual Diameter [diameter] | Current Rating (Amps) | Features | Body Color | Housing Material | Voltage - Rated | Contact Material | Internal Switch(s) | Mating Length/Depth | Mating Length/Depth | Contact Material - Plating | Body Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Same Sky (Formerly CUI Devices) | 4 | 3 | Phone Jack | 2.5 mm | 0.094 " | 3 /32" | Single Switch | -20 ░C | 60 °C | Stereo (3 Conductor TRS) | Solder | Female | Unshielded | Right Angle Through Hole | 2.6 mm | 0.102 in | |||||||||||
 Same Sky (Formerly CUI Devices) | 3 | 3 | Phone Jack | 2.5 mm | 0.094 " | 3 /32" | -25 °C | 85 °C | Stereo (3 Conductor TRS) | Solder | Female | Unshielded | Right Angle Surface Mount | 2.6 mm | 0.102 in | 1 A | Board Guide | Black | Polyamide (PA10T) Nylon 10T | 12 VDC | Copper Alloy | 11 mm | 0.433 in | Silver | |||
Same Sky (Formerly CUI Devices) | 3 | 3 | Phone Jack | 2.5 mm | 0.094 " | 3 /32" | -25 °C | 85 °C | Stereo (3 Conductor TRS) | Solder | Female | Unshielded | Right Angle Surface Mount | 2.6 mm | 0.102 in | Board Guide | |||||||||||
 Same Sky (Formerly CUI Devices) | 4 | 4 | Phone Jack | 2.5 mm | 0.094 " | 3 /32" | -25 °C | 85 °C | Stereo (4 Conductor TRRS) | Solder | Female | Unshielded | Right Angle Surface Mount | 2.6 mm | 0.102 in | 1 A | Board Guide | Black | Polyamide (PA10T) Nylon 10T | 12 VDC | Copper Alloy | 11 mm | 0.433 in | Gold | |||
 Same Sky (Formerly CUI Devices) | 4 | 3 | Phone Jack | 2.5 mm | 0.094 " | 3 /32" | -20 ░C | 60 °C | Stereo (3 Conductor TRS) | Solder | Female | Unshielded | Right Angle Through Hole | 2.6 mm | 0.102 in | 1 A | Black Silver | Polyoxymethylene (POM) | 12 VDC | Phosphor Bronze | Silver | Brass | |||||
 Same Sky (Formerly CUI Devices) | 3 | 3 | Phone Jack | 2.5 mm | 0.094 " | 3 /32" | -25 °C | 85 °C | Stereo (3 Conductor TRS) | Solder | Female | Unshielded | Right Angle Surface Mount | 2.6 mm | 0.102 in | 1 A | Black | Nylon 6T Polyamide (PA6T) | 12 VDC | Copper Alloy | Gold | ||||||
 Same Sky (Formerly CUI Devices) | 3 | 3 | Phone Jack | 2.5 mm | 0.094 " | 3 /32" | -20 ░C | 60 °C | Stereo (3 Conductor TRS) | Solder | Female | Unshielded | Right Angle Through Hole | 2.6 mm | 0.102 in | 1 A | Black | Polybutylene Terephthalate (PBT) | 12 VDC | Brass | Tin | ||||||
Same Sky (Formerly CUI Devices) | 4 | 3 | Phone Jack | 2.5 mm | 0.094 " | 3 /32" | -20 ░C | 60 °C | Stereo (3 Conductor TRS) | Solder | Female | Unshielded | Right Angle Through Hole | 2.6 mm | 0.102 in | ||||||||||||
Same Sky (Formerly CUI Devices) | 4 | 4 | Phone Jack | 2.5 mm | 0.094 " | 3 /32" | -25 °C | 85 °C | Stereo (4 Conductor TRRS) | Solder | Female | Unshielded | Right Angle Surface Mount | 2.6 mm | 0.102 in | Board Guide | |||||||||||
Same Sky (Formerly CUI Devices) | 4 | 3 | Phone Jack | 2.5 mm | 0.094 " | 3 /32" | Single Switch | -20 ░C | 60 °C | Stereo (3 Conductor TRS) | Solder | Female | Unshielded | Right Angle Through Hole | 2.6 mm | 0.102 in | 1 A | Black | Polybutylene Terephthalate (PBT) | 12 VDC | Brass | Tin |
