Holsworthy RQ73 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
RQ 1206 316R 0.1% 10PPM 1K RL
| Part | Power (Watts) | Power (Watts) | Features | Supplier Device Package | Resistance | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Operating Temperature [Max] | Operating Temperature [Min] | Temperature Coefficient | Composition | Package / Case | Tolerance | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Number of Terminations [custom] | Ratings | Power (Watts) [Min] | Power (Watts) [Max] | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | |||||||||||||||||||||||
 TE Connectivity AMP Connectors | 0.2 W | 0.2 W | Anti-Sulfur Automotive AEC-Q200 | 0805 | 69.8 Ohms | 2 mm | 1.25 mm | 0.049 " | 0.079 in | 155 C | -55 C | 10 ppm/°C | Thin Film | 0805 | 0.1 % | 0.026 in | 0.65 mm | 2 | |||||
 TE Connectivity AMP Connectors | 0.4 W | Anti-Sulfur Automotive AEC-Q200 | 1206 | 576 kOhms | 3.1 mm | 1.6 mm | 0.063 " | 0.122 " | 155 C | -55 C | 10 ppm/°C | Thin Film | 1206 (3216 Metric) | 0.1 % | 2 | AEC-Q200 | 2 W | 5 W | 0.03 " | 0.75 mm | |||
 TE Connectivity AMP Connectors | 0.2 W | 0.2 W | Anti-Sulfur Automotive AEC-Q200 | 0805 | 14300 Ohms | 2 mm | 1.25 mm | 0.049 " | 0.079 in | 155 C | -55 C | 10 ppm/°C | Thin Film | 0805 | 0.1 % | 0.026 in | 0.65 mm | 2 | AEC-Q200 | ||||
TE Connectivity AMP Connectors | |||||||||||||||||||||||
 TE Connectivity AMP Connectors | |||||||||||||||||||||||
 TE Connectivity AMP Connectors | 0.4 W | Anti-Sulfur Automotive AEC-Q200 | 1206 | 75 Ohms | 3.1 mm | 1.6 mm | 0.063 " | 0.122 " | 155 C | -55 C | 10 ppm/°C | Thin Film | 1206 (3216 Metric) | 0.1 % | 2 | 2 W | 5 W | 0.03 " | 0.75 mm | ||||
TE Connectivity AMP Connectors | 0.4 W | Anti-Sulfur Automotive AEC-Q200 | 1206 | 44.2 Ohms | 3.1 mm | 1.6 mm | 0.063 " | 0.122 " | 155 C | -55 C | 10 ppm/°C | Thin Film | 1206 (3216 Metric) | 0.1 % | 2 | 2 W | 5 W | 0.03 " | 0.75 mm | ||||
 TE Connectivity AMP Connectors | 0.2 W | 0.2 W | Anti-Sulfur Automotive AEC-Q200 Moisture Resistant | 0805 | 2.26 kOhms | 2 mm | 1.25 mm | 0.049 " | 0.079 in | 155 C | -55 C | 10 ppm/°C | Thin Film | 0805 | 0.1 % | 0.026 in | 0.65 mm | 2 | AEC-Q200 | ||||
TE Connectivity AMP Connectors | 0.2 W | 0.2 W | Anti-Sulfur Automotive AEC-Q200 Moisture Resistant | 0805 | 26.7 Ohms | 2 mm | 1.25 mm | 0.049 " | 0.079 in | 155 C | -55 C | 10 ppm/°C | Thin Film | 0805 | 0.1 % | 0.026 in | 0.65 mm | 2 | AEC-Q200 |
