har-flexicon TSPH Series
Manufacturer: HARTING
Beta
⌘K
WIRE-TO-BOARD TERMINAL BLOCK, 2.54 MM, 7 POSITIONS, 24 AWG, 20 AWG, CLAMP
| Part | Contact Material - Plating | Housing Material | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Wire Gauge [Min] | Wire Gauge [Max] | Pitch | Pitch | Voltage | Color | Current | Features | Wire Termination | Positions Per Level [custom] | Number of Levels | Mating Orientation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 HARTING | Copper Alloy - Tin Plated | Glass Filled Liquid Crystal Polymer (LCP) | 125 °C | -40 C | Surface Mount | 19.5 AWG | 26 AWG | 0.1 " | 2.54 mm | 160 V | Black | 6 A | Board Guide Solder Retention | Screwless - Spring Cage Tension Clamp | 7 | 1 | Horizontal with Board |
