F Series

Catalog

SAFETY CAPACITORS F 2KV 1NF +/- 10% Y5R AMMO E3

Part	Lead Style	Applications	Package / Case	Tolerance	Features	Lead Spacing	Mounting Type	Temperature Coefficient	Size / Dimension Diameter	Voltage - Rated	Capacitance	Operating Temperature (Min)	Operating Temperature (Max)
Vishay Dale F102K29Y5RL6UJ5R	Formed Leads - Kinked	SMPS Filtering	Disc Radial	10 %	High Voltage	0.197 in	Through Hole	Y5R	0.295 in	2000 VAC	1000 pF	-30 °C	125 °C
Vishay Dale F152K43Y5RN6TJ7R	Formed Leads - Kinked	SMPS Filtering	Disc Radial	10 %	High Voltage	0.295 in	Through Hole	Y5R	0.433 in	1000 V	1500 pF	-30 °C	125 °C
Vishay Dale F681K43Y5RR6TK7R	Formed Leads - Kinked	SMPS Filtering	Disc Radial	10 %	High Voltage	0.295 in	Through Hole	Y5R	0.433 in	3000 V	680 pF	-30 °C	125 °C
Vishay Dale F471K25S3NN63J5R	Formed Leads - Kinked	SMPS Filtering	Disc Radial	10 %	High Voltage	0.197 in	Through Hole	S3N	0.256 in	1000 V	470 pF
Vishay Dale F152K33Y5RL6UJ5R	Formed Leads - Kinked	SMPS Filtering	Disc Radial	10 %	High Voltage	0.197 in	Through Hole	Y5R	0.335 in	500 V	1500 pF	-30 °C	125 °C
Vishay Dale F331K29Y5RP63K5R	Formed Leads - Kinked	SMPS Filtering	Disc Radial	10 %	High Voltage	0.197 in	Through Hole	Y5R	0.295 in	2000 VAC	330 pF	-30 °C	125 °C
Vishay Dale F102K39Y5RN6UJ5R	Formed Leads - Kinked	SMPS Filtering	Disc Radial	10 %	High Voltage	0.197 in	Through Hole	Y5R	0.394 in	1000 V	1000 pF	-30 °C	125 °C
Vishay Dale F102K43Y5RP63K5R	Formed Leads - Kinked	SMPS Filtering	Disc Radial	10 %	High Voltage	0.197 in	Through Hole	Y5R	0.433 in	2000 VAC	1000 pF	-30 °C	125 °C
Vishay Dale F471K29Y5RN63K5R	Formed Leads - Kinked	SMPS Filtering	Disc Radial	10 %	High Voltage	0.197 in	Through Hole	Y5R	0.295 in	1000 V	470 pF	-30 °C	125 °C
Vishay Dale F221K29S3NR63K7R	Formed Leads - Kinked	SMPS Filtering	Disc Radial	10 %	High Voltage	0.295 in	Through Hole	S3N	0.295 in	3000 V	220 pF
