205865 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONN D-SUB PLUG 9POS R/A SOLDER
| Part | Dielectric Material | Color | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating | Backset Spacing | Backset Spacing | Flange Feature | Termination | Contact Finish Thickness | Mounting Type | Current Rating (Amps) | Number of Positions | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Material Flammability Rating | Connector Type | Connector Style | Number of Rows [custom] | Contact Type | Features | Contact Finish | Shell Material, Finish [custom] | Shell Material, Finish [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Glass Filled Nylon Polyamide (PA) | Black | -55 C | 105 ░C | 125 VDC | 13.84 mm | 0.545 in | Mating Side Standard Screws (4-40) | Solder | Flash | Right Angle Through Hole | 6 A | 9 | 1 | DE E | UL94 V-0 | Plug Male Pins | D-Sub | 2 | Signal | Mounting Brackets | Gold | Yellow Chromate Plated Zinc | Steel |
