AZH203 Series

Catalog

SWITCH SNAP ACTION SPDT 5A 125V

Part	Operating Force	Mechanical Life	Release Force	Actuator Type	Current Rating (Amps)	Pretravel	Pretravel	Termination Style	Voltage Rating - DC	Mounting Type	Overtravel	Overtravel	Operating Temperature [Min]	Operating Temperature [Max]	Operating Position	Operating Position	Circuit	Switch Function	Voltage Rating - AC	Electrical Life	Differential Travel	Differential Travel	Ingress Protection
Panasonic Industrial Automation Sales AZH2033	1200 gf	10000000 Cycles	500 gf	Cross Roller Plunger	5 A	0.06 in	1.5 mm	Screw Terminal	30 V	Panel Mount	0.118 "	3 mm	-10 °C	80 °C	0.922 in	23.4 mm	SPDT	On-Mom	125 V	100000 Cycles	0.1 mm	0.004 in	IP67 - Dust Tight Waterproof
Panasonic Industrial Automation Sales AZH2031	1200 gf	10000000 Cycles	500 gf	Round (Pin Plunger)	5 A	0.06 in	1.5 mm	Screw Terminal	30 V	Panel Mount	0.118 "	3 mm	-10 °C	80 °C	0.685 in	17.4 mm	SPDT	On-Mom	125 V	100000 Cycles	0.1 mm	0.004 in	IP67 - Dust Tight Waterproof
