Lexium 32 Series

Catalog

AC, DC & SERVO MOTORS MOTOR 70 IP65 KEYED ABS BRK ANGLED

...

Part	Length - Shaft and Bearing	Length - Shaft and Bearing	Function	Torque - Rated (oz-in / mNm)	Torque - Rated (oz-in / mNm)	Mounting Hole Spacing [custom]	Mounting Hole Spacing [custom]	RPM	Termination Style	Features	Power - Rated	Diameter - Shaft [diameter]	Diameter - Shaft [diameter]	Voltage - Rated	Type	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Length - Shaft and Bearing [x]	Length - Shaft and Bearing [x]	Size / Dimension
SCHNEIDER ELECTRIC BSH0702P32F2A	23 mm	0.906 in	Servomotor	1900 mNm	269.1 oz-in	60 mm	2.362 in	8000 RPM	Connector	Brake Key	1300 W	0.433 in	11 mm	480 VAC	AC Motor
SCHNEIDER ELECTRIC BSH0551P12F1A	20.07 mm	0.79 in	Servomotor	480 mNm	67.97 oz-in	39.88 mm	1.57 in	9000 RPM	Connector	Brake Key	300 W	0.35 in	8.89 mm	480 VAC	AC Motor	2.17 "	2.17 "	55.12 mm	55.12 mm
SCHNEIDER ELECTRIC BSH0553P12A2A			Servomotor	1100 mNm	155.8 oz-in	40 mm	1.575 in	9000 RPM	Connector	Key	670 W	0.354 in	9 mm	480 VAC	AC Motor	2.165 in	2.165 in	55 mm	55 mm	20 mm	0.787 in	Square
SCHNEIDER ELECTRIC BMH1402P31A1A
SCHNEIDER ELECTRIC BMH0703P02F2A	29.97 mm		Servomotor	2400 mNm	339.8 oz-in	59.94 mm	2.36 in	8000 RPM	Connector	Brake	1300 W	0.55 in	13.97 mm	480 VAC	AC Motor	2.76 "	2.76 "	70.1 mm	70.1 mm		1.18 in
SCHNEIDER ELECTRIC BSH0551P02A1A	20.07 mm	0.79 in	Servomotor	480 mNm	67.97 oz-in	39.88 mm	1.57 in	9000 RPM	Connector		300 W	0.354 in	9 mm	480 VAC	AC Motor	2.165 in	2.165 in	55 mm	55 mm			Square
SCHNEIDER ELECTRIC BSH0702P01F2A	23.11 mm	0.91 in	Servomotor	1900 mNm	269.1 oz-in	59.94 mm	2.36 in	8000 RPM	Connector	Brake	1300 W	0.43 in	10.92 mm	480 VAC	AC Motor	2.76 "	2.76 "	70.1 mm	70.1 mm
SCHNEIDER ELECTRIC BMH2052P22A2A	80 mm	3.15 in	Servomotor	41600 mNm	5891 oz-in	180 mm	7.087 in	3800 RPM	Connector		6.5 kW	1.5 in	38.1 mm	480 VAC	AC Motor	8.071 in	8.071 in	205 mm	205 mm
SCHNEIDER ELECTRIC BMH1903P21F2A	80 mm	3.15 in	Servomotor	37000 mNm	5240 oz-in	180 mm	7.087 in	3500 RPM	Connector	Brake	7.75 kW	1.496 in	38 mm	480 VAC	AC Motor	7.48 in	7.48 in	190 mm	190 mm
SCHNEIDER ELECTRIC BSH0552P02F1A	20.07 mm	0.79 in	Servomotor	2700 mNm	382.4 oz-in	39.88 mm	1.57 in	9000 RPM	Connector	Brake	400 W	0.354 in	9 mm	480 VAC	AC Motor	2.165 in	2.165 in	55 mm	55 mm			Square
