KP236N6165 Series
Manufacturer: INFINEON
Beta
⌘K
SENSOR 23.93PSIA 4.8V DSOF8
| Part | Applications | Output Type | Package / Case | Termination Style | Grade | Mounting Type | Features | Accuracy | Accuracy | Voltage - Supply [Max] | Voltage - Supply [Min] | Qualification | Output [Max] | Output [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Port Style | Operating Pressure [Min] | Operating Pressure [Max] | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 INFINEON | Board Mount | Analog Voltage | 8-SMD Module | SMD (SMT) Tab | Automotive | Surface Mount | Amplified Output Temperature Compensated | 2 kPa | 0.29 PSI | 5.5 V | 4.5 V | AEC-Q100 | 4.8 V | 0.2 V | 125 °C | -40 C | No Port | 8.7 PSI 60 kPa | 23.93 PSI 165 kPa | |
 INFINEON | Board Mount | Analog Voltage | 8-SMD Module | SMD (SMT) Tab | Automotive | Surface Mount | Amplified Output Temperature Compensated | 2 kPa | 0.29 PSI | 5.5 V | 4.5 V | AEC-Q100 | 4.85 V | 0.1 V | 125 °C | -40 C | No Port | 8.7 PSI 60 kPa | 23.93 PSI 165 kPa | PG-DSOF-8-16 |
