0022 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
0022E0111-90
| Part | Shield Material | Shield Coverage | Dielectric Diameter [diameter] | Dielectric Diameter [diameter] | Conductor Material | Dielectric Material | Shield Type | Impedance | Conductor Strand [custom] | Conductor Strand [custom] | Wire Gauge | Cable Type | VoP, Velocity of Propagation | Jacket (Insulation) Material | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Jacket Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | |||||||||||||||||
 TE Connectivity AMP Connectors | Copper Tinned | 90 % | 0.095 in | 2.41 mm | Copper Tinned | Ethylene Tetrafluoroethylene (ETFE) | Braid | 100 Ohms | 19 | 34 AWG | 22 AWG | Twinaxial | |||||
TE Connectivity AMP Connectors | Copper Tinned | 90 % | 0.078 in | 1.98 mm | Copper Tinned | Braid | 100 Ohms | 19 | 34 AWG | 22 AWG | Twinaxial | 75 | Thermorad® S | 0.203 in | 5.16 mm | Black |
