TFSS Series
Manufacturer: Ohmite
Beta
⌘K
THICK FILM RESISTORS - SMD SMD SURGE RESISTOR, THICK FILM 55J 220 OHMS 1%
| Part | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Tolerance | Package / Case | Number of Terminations [custom] | Resistance | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Composition | Features | Operating Temperature [Min] | Operating Temperature [Max] | Power (Watts) | Temperature Coefficient | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Power (Watts) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Ohmite | 0.035 in | 0.9 mm | 1 % | Nonstandard | 2 | 220 Ohms | 10.5 mm | 0.413 in | 26 mm | 1.024 in | Thick Film | Non-Inductive Pulse Withstanding | -40 C | 155 C | 2 W | 100 ppm/°C | |||
Ohmite | 5 % | Nonstandard | 2 | 470 Ohms | 5.5 mm | 0.217 in | 11 mm | 0.433 in | Thick Film | Non-Inductive Pulse Withstanding | -40 C | 155 C | 0.5 W | 100 ppm/°C | 0.7 mm | 0.028 " | 0.5 W |
